Graco LineLazer V 200HS - Technical Specifications (LineLazer V 200 DC Standard Series)

Technical Specifications
64 3A3426EOperation
Wetted Parts: PTFE, Nylon, polyurethane, V-Max,
UHMWPE, fluoroelastomer, acetal, leather, tungsten
carbide, stainless steel, chrome plating, nickel-plated
carbon steel, ceramic
LineLazer V 200DC Standard Series (Model 17Y231)
U.S. Metric
Dimensions
Height (with handle bar down)
Unpackaged - 44.5 in.
Packaged - 52.5 in.
Unpackaged - 113.03 cm
Packaged - 133.35 cm
Width Unpackaged - 34.25 in.
Packaged - 37.0 in.
Unpackaged - 87.0 cm
Packaged - 93.98 cm
Length (with platform down)
Unpackaged - 68.75 in.
Packaged - 73.5 in.
Unpackaged - 174.63 cm
Packaged - 186.69 cm
Weight (dry - no paint) Unpackaged - 411 lbs
Packaged - 477 lbs
Unpackaged - 186 kg
Packaged - 216 kg
Noise (dBa)
Sound Power per ISO 9614:
99.0
Sound Pressure per ISO 9614:
85.5
Vibration (m/s
2
) (8 hours daily exposure)
Hand Arm (per ISO 5349)
Left hand 1.71
Right hand 2.23
Whole Body (per ISO 2631) 0.4
Power Rating (Horse Power)
Power Rating (Horse Power) per SAE J1349
6.5 HP @ 3600 rpm 4.84 kW @ 3600 rpm
Maximum Delivery
2.15 gpm 8.14 lpm
Maximum Tip Size
1 gun
2 gun
.047
.034
Inlet paint strainer 16 mesh 1190 micron
Outlet paint strainer 50 mesh 297 micron
Pump inlet size 1 in. NSPM (m)
Pump outlet size 3/8 NPT (f)
Maximum working pressure 3300 psi 228 bar, 22.8 MPa
Maximum fluid working pressure 3300 psi 228 bar, 22.8 MPa
Maximum free-flow delivery 2.15 gpm 8.14 lpm
Cycles per gallon/liter 62 cpg 16.4 cpl
Hydraulic reservoir capacity 1.25 gallons 4.73 liters
Hydraulic pressure 1825 psi 124 bar
Electrical Capacity 84 W@ 3600 rpm
Battery 12V, 22Ah, Sealed lead acid, Deep cycle
