Graco PR70 - Page 34

Parts
34 312760A
Fixed Ratio Base, continued
FIG. 10
100a
100c
102
101
Torque to 85 in-lb (9.6 N•m).
Torque to 350 in-lb (39.5 N•m).
Retaining ring must rest against
pump body.
1
2
4
2
1
4
ti12487a
117
112
120
ti12476a
117a
