Parts
54 312760A
Dispense Valve
Standard Dispense Valves, 255179 and
277181
See MD2 Dispense Valve manual referenced at the
beginning of this manual.
Gun Mounted MD2 Valves, LC0120 and LC0122
† See MD2 manual referenced at the beginning of this manual for dispense valve parts information.
902
903
901a
902b
ti12440a
Assembly LC0120 Shown
Ref Part Description Qty
901 LC0006 VALVE, assembly, 10:1, gun, electric
(assembly LC0122 only)
1
LC0004 VALVE, assembly, 1:1, gun, electric
(assembly LC0120 only)
1
901a
†
255181 VALVE, dispense, 10:1, soft seats
(assembly LC0122 only)
1
†
255179 VALVE, dispense, 1:1, soft seats
(assembly LC0120 only)
1
901b 255208 HANDLE, 2K dispense valve, electric 1
902 121198 CORD, euro, male, 4 pin, 3 wire, 6 m 1
903 120953 CONNECTOR, splitter 1
To Next Page
