Parts
312760A 49
*Not shown.
Ref Part Description Qty
301 119912 SCREW, mach. phillips pan
hd.
3
302 121018 FITTING, elbow, male,
swivel, 1/4 npt
1
303 120876 POWER SUPPLY 1
304 120882 FILTER 1
305 120883 NUT 1
306 120910 SOCKET, electrical, with emi
filter
1
307 120916 SCREW 6
308 120993 NUT, hex, M5, with tooth
washer
2
309 15U738 BRACKET, incoming power 1
310 15K800 FITTING, bulkhead 1
311 * 84/0130-26/11 LABEL, symbol, pe 1
312 121581 HARNESS, I/O, M12 x M12 1
313 121178 VALVE, 1/4 in. OSHA lockout 1
314 121179 CLAMP, norgren, quikclamp
4214-51
2
315 * 121180 MANIFOLD, norgren quik-
clamp 4216-50
1
316 94/0762/99 VALVE, safety, blow-off, 100
psi
1
317 94/0387/99 PLUG, pipe, 1/4 npt 2
318 81/1054-4/11 FUSE, type f, 4 amp, 250v,
fast
1
319 LC0291 CABLE, power, assembly 1
320 81/9996-N/11 TERMINAL, socket, spade,
insulated
9
321 81/9998-A/11 TERMINAL, fork, insulated 3
322 81/9997-M/11 TERMINAL, ring, insulated 2
325 * 84/2725-1/11 LABEL, symbol, CE 1
326 121558 CONNECTOR, power, panel
mount
2
327 121677 TERMINAL, piggyback,
socket
6
328 * 81/0052-W/11 WIRE, 18 ga, mtw, strand,
wht
1
329 15V092 LABEL, bracket, incoming,
power
1
330 104395 WASHER, lock, tooth, exter-
nal
1
Ref Part Description Qty
