Repair
332144E 53
Replace Cycle Counter Switch
NOTE: RES side drive housing cover (229) includes the
cycle counter switch (223), mounted in the cover. When
reassembling, be sure to install cover with switch on
RES side.
TI7028a
223
0.6 in. (15.2 mm)
from inside edge
1.0 in. (25.4 mm)
from inside bottom
edge
FIG. 18. Drive Housing
Crankshaft must be in line with crankshaft at other end of motor,
so pumps move up and down in unison.
1
229
215
224
210
201
220
207
ti21847a
1
MB
216
212
(steel)
213
(bronze)
208
(steel)
211
(bronze)
209
(bronze)
219
213
(bronze)
214
221
223
89
91
233
