Technical Data
76 332144E
Technical Data
Reactor E-10hp US Metric
Maximum fluid working pressure 3000 psi 20.6 MPa, 206 bar
Maximum spray pressure: 120 V 2200 psi 15.2 MPa, 152 bar
Maximum spray pressure: 230 V 2500 psi 17.2 MPa, 172 bar
Maximum fluid temperature 170°F 77°C
Maximum ambient temperature 120°F 48°C
Maximum output 1 gal./min 3.8 liters/min
Output per cycle (ISO and RES) 0.0038 gallons/cycle 0.014 liters/cycle
Air inlet 1/4 in. quick-disconnect industrial type pin fitting
Air outlet 1/4 npsm(m)
Overpressure relief Recirc/Spray valves automatically relieve excessive fluid pressure back to
supply tanks
Gun compressed air requirements
Fusion Gun (purge air and operating air): 4 scfm (0.112 m
3
/min)
Maximum hose length 105 ft 32 m
Tank capacity each (nominal) 6 gal. 22.7 liters
Weight (empty) 239 lb 108 kg
Recommended Mix Chamber Sizes
Fusion
®
Air Purge
000, AW2222 (00 and 01 at reduced spray pressure)
Probler
®
P2
AA (00 and 01 at reduced spray pressure)
Electrical Requirements
120 V 100-120VAC, 1 phase, 50/60 Hz, 3840 W; requires two separate,
dedicated 20 A circuits. Full load peak amperage 16 A per circuit.
230 V 200-240VAC, 1 phase, 50/60 Hz, 5520 W; requires two separate,
dedicated 15 A circuits. Full load peak amperage 12 A per circuit.
Generator Size
120 V 5000 W minimum
230 V 7500 W minimum
Heater Power
120 V 3000 W during recirculation, 2000 W during pressure spray mode
230 V 4000 W during recirculation, 2760 W during pressure spray mode
Sound Pressure
In fast recirculation mode 71.3 dB(A)
Measure at 2500 psi (17 MPa, 172
bar), 1 gpm (3.8 lpm)
85.6 dB(A)
Sound Power*
In fast recirculation mode 79.9 dB(A)
Measure at 2500 psi (17 MPa, 172
bar), 1 gpm (3.8 lpm)
93.3 dB(A)
