Graco SlimFit3 LX User Manual

Vehicle Information
10
108
Always review your vehicle owner’s manual for specific information
about your vehicle seat belts.
Lap Belt Installation - DO NOT use in Booster Mode
Locking Latch Plate and No Retractor
When installing the car seat, route the lap seat belt
through the proper path and buckle it in. Then, pull
upwards on the tail of the belt so that the lap belt
gets tight around the car seat.
Sewn On Latch Plate and ALR
Slowly pull the lap belt all the way out. Route
the vehicle seat lap belt through the proper belt
path and buckle it in. Then, pull the lap belt tight
while feeding all the slack back into the retractor.
Grab the sides of the seat
at the belt path and slide
the seat side-to-side and
front-to-back. The seat
should not move more
than 1“ (2.5 cm).
NWL0001077519C SlimFit3 LX USA ENG R04 (8BZ20.indd 108NWL0001077519C SlimFit3 LX USA ENG R04 (8BZ20.indd 108 9/18/20 11:50 AM9/18/20 11:50 AM

Graco SlimFit3 LX Specifications

General

Product Type	3-in-1 Car Seat
Rear-Facing Weight Capacity	5-40 lbs
Forward-Facing Weight Capacity	22-65 lbs
Booster Mode Weight Range	40-100 lbs
Height Capacity	Up to 57 inches
Harness Type	5-point harness
Harness Positions	10
Side Impact Protection	Yes
Cup Holders	2
Machine Washable Cover	Yes
Weight Capacity	5-100 lbs
Installation	LATCH
Recline Positions	4
