Graco SlimFit3 LX User Manual

Important
1
Important
1
12
Does Your Car Seat Fit Your Child Correctly?
To make sure your child is secured properly, review sections 4, 5, 6, and 7 to understand all
of the actions you need to take to properly adjust the car seat to fit your child.
Harness Height, Rear-Facing (A)
Harness straps at or just below the child’s shoulders.
Top of head must be 1” (2.5 cm) below the headrest
adjustment lever (B).
Review section 6.
Harness Height, Forward-Facing (C)
Harness straps at or just above the child’s shoulders
and top of child’s ears below top of headrest (D).
Review section 6.
Buckle Position (E)
The correct slot is the one that is closest to your child
without being underneath them. For forward-facing, do
NOT use inner-most slot.
Review section 6.
Harness Tightness (F)
If your fingers slide off the harness straps without
pinching the straps, it is tight enough.
Review section 6.
For Rear-Facing and Forward-Facing, You Need to Adjust:
1” (2.5 cm)1” (2.5 cm)
BA
DC
E F
NWL0001077519C SlimFit3 LX USA ENG R04 (8BZ20.indd 12NWL0001077519C SlimFit3 LX USA ENG R04 (8BZ20.indd 12 9/18/20 11:49 AM9/18/20 11:49 AM

Graco SlimFit3 LX Specifications

General

Product Type	3-in-1 Car Seat
Rear-Facing Weight Capacity	5-40 lbs
Forward-Facing Weight Capacity	22-65 lbs
Booster Mode Weight Range	40-100 lbs
Height Capacity	Up to 57 inches
Harness Type	5-point harness
Harness Positions	10
Side Impact Protection	Yes
Cup Holders	2
Machine Washable Cover	Yes
Weight Capacity	5-100 lbs
Installation	LATCH
Recline Positions	4
