Graco SlimFit3 LX User Manual

Forward-Facing with LATCH
5-C
61
5-C Install Forward-Facing with LATCH
1. Remove Lower Anchor Attachment from
Storage Location
Lift seat pad and remove lower anchor
connectors from storage location. First, push
on the tab on the seat in front of the lower
anchor connector (A) and then pull on the
lower anchor strap to remove the lower anchor
connector (B). Repeat on the other side.
2. Make Sure Lower Anchor Strap is in the
Forward-Facing Belt Path Marked with
Orange Label
To move the lower anchor strap, review
section 8.
A
B
Review your vehicle’s owner manual for LATCH location and use. Do not install
by this method for a child weighing more than 45 lb (20 kg).
Visit www.gracobaby.com
and the Graco
®
SlimFit3™
LX car seat product page
to view installation videos.
NWL0001077519C SlimFit3 LX USA ENG R04 (8BZ20.indd 61NWL0001077519C SlimFit3 LX USA ENG R04 (8BZ20.indd 61 9/18/20 11:49 AM9/18/20 11:49 AM

Graco SlimFit3 LX Specifications

General

Product Type	3-in-1 Car Seat
Rear-Facing Weight Capacity	5-40 lbs
Forward-Facing Weight Capacity	22-65 lbs
Booster Mode Weight Range	40-100 lbs
Height Capacity	Up to 57 inches
Harness Type	5-point harness
Harness Positions	10
Side Impact Protection	Yes
Cup Holders	2
Machine Washable Cover	Yes
Weight Capacity	5-100 lbs
Installation	LATCH
Recline Positions	4
