Graco SlimFit3 LX User Manual

Rear Facing
4-A
36
4-A Rear-Facing Use
Rear-Facing:
5-40 lb (2.2-18 kg) and whose
head is at least 1” (2.5 cm)
below the headrest adjustment
handle
• Infants who weigh less than 22 lb (10 kg) MUST
be rear-facing.
• Place car seat rear-facing in the vehicle back seat.
• Make sure lower anchor strap or vehicle seat belt
is routed through the rear-facing belt path marked
with a blue label.
• Install this car seat tightly in your vehicle. Car
seat should not move at the rear-facing belt path
more than 1” (2.5 cm) from side to side, front to
back.
• Check recline level making sure the ball is within
the blue area. Vehicle MUST be on level ground.
• Harness straps need to be at or just below
the top of child’s shoulders and chest clip is at
armpit level.
Vehicle Seat Lap/
Shoulder Belt
Vehicle Seat Lap Belt
Visit www.gracobaby.com
and the Graco
®
SlimFit3™
LX car seat product page
to view installation videos.
NWL0001077519C SlimFit3 LX USA ENG R04 (8BZ20.indd 36NWL0001077519C SlimFit3 LX USA ENG R04 (8BZ20.indd 36 9/18/20 11:49 AM9/18/20 11:49 AM

Graco SlimFit3 LX Specifications

General

Product Type	3-in-1 Car Seat
Rear-Facing Weight Capacity	5-40 lbs
Forward-Facing Weight Capacity	22-65 lbs
Booster Mode Weight Range	40-100 lbs
Height Capacity	Up to 57 inches
Harness Type	5-point harness
Harness Positions	10
Side Impact Protection	Yes
Cup Holders	2
Machine Washable Cover	Yes
Weight Capacity	5-100 lbs
Installation	LATCH
Recline Positions	4
