Graco SlimFit3 LX User Manual

Rear Facing with Lower Anchor Attachment
4-C
48
9. Connect the Lower Anchor Connectors to
Vehicle’s Lower Anchors
Make sure that the arrows are pointing up.
Lower anchor strap should not be twisted. If
twisted, you will not be able to tighten the strap.
Lower anchor connectors can only be used if
the vehicle lower anchor spacing is 11 inches
(28 cm) from the center of one lower anchor to
the center of the other lower anchor.
CLICK!
11” (28 cm)
NWL0001077519C SlimFit3 LX USA ENG R04 (8BZ20.indd 48NWL0001077519C SlimFit3 LX USA ENG R04 (8BZ20.indd 48 9/18/20 11:49 AM9/18/20 11:49 AM

Graco SlimFit3 LX Specifications

General

Product Type	3-in-1 Car Seat
Rear-Facing Weight Capacity	5-40 lbs
Forward-Facing Weight Capacity	22-65 lbs
Booster Mode Weight Range	40-100 lbs
Height Capacity	Up to 57 inches
Harness Type	5-point harness
Harness Positions	10
Side Impact Protection	Yes
Cup Holders	2
Machine Washable Cover	Yes
Weight Capacity	5-100 lbs
Installation	LATCH
Recline Positions	4
