Page | 36

GRP261X /GRP2624/GRP2634 User Guide

Version 1.0.5.48

Figure 9: GRP2615 Keyboard

Figure 10: GRP2616 Keyboard

Table 9: GRP261X/GRP2624/GRP2634 Keypad Buttons

Contacts. Press to view and edit contact information.

Hold. Press to put call on hold or resume the call.

Mute. Press to mute or unmute the call.

Table of Contents8
