HT801/HT802 Administration Guide
Version 1.0.13.7
Dynamically assigned via
DHCP
All the field values for the static IP mode are not used (even though they
are still saved in the flash memory.) The HT801/802 acquires its IP address
from the first DHCP server it discovers from the LAN it is connected.
• DHCP hostname: Specifies the name of the client. The name may
or may not be qualified with the local domain name. This field is
optional but may be required by ISP.
• DHCP vendor class ID: Exchanges vendor class ID by clients and
servers to convey particular configuration or other identification
information about a client. Default is HT8XX.
Set the PPPoE account settings. If selected, ATA attempt to establish a
PPPoE session if any of the PPPoE fields is set.
• PPPoE account ID: Defines the PPPoE username. Necessary if
ISP requires you to use a PPPoE (Point to Point Protocol over
Ethernet) connection.
• PPPoE password: Specifies the PPPoE account password.
• PPPoE Service Name: Defines PPPoE service name. If your ISP
uses a service name for the PPPoE connection, enter the service
name here. This field is optional. Default is blank.
Specifies preferred DNS server to use when DHCP or PPPoE are set.
Statically configured as IP
address
Configure IP address, subnet Mask, default router IP address, 1
st
preferred
DNS server, 2
nd
preferred DNS server. These fields are set to zero by
default.
Allows users to configure the appropriate network settings on the HT80x to
obtain IPv6 address. Users could select "DHCP", "Static IP”. By default, it
is set to "DHCP".
• DHCP mode: all the field values for the static IP mode are not used
(even though they are still saved in the flash memory.) The
HT801/HT802 acquires its IP address from the first DHCP server it
discovers from the LAN it is connected.
• Static IP mode: configure IP address, 1
st
and 2
nd
DNS server,
preferred DNS server. These fields are set to zero by default.
