Section 9: CommissioningPage 46
9.7 Parameters Input/Output
The following parameter settings must be checked on commissioning.
Table 9-2: Parameters input/output
Level
Parameter
Function description
Display and input value
Remarks
Group Code Default Min. Max. Unit
I 51 19
Terminal 19-18 : DHW remote contact
0=disable (Remote controller only)
1=enable
1 0 1 -
I 51 20
Terminal 20-21 : ON/OFF remote contact (CH)
Alarm input
0=disable
1=ON/OFF remote contact
1 0 1 -
ON/OFF by
Remote controller
0=enable
1=ON/disable
OFF/enable
2=enable
I 51 28
Terminal 28-29 : Night mode*
0=disable
1=enable
Refer to Section 8.6.
0 0 1 -
Parameter 5128
and Parameter
5130 are
synchronised in
same value
I 51 30
Terminal 30-31 : Low tariff*
0=disable
1=enable
Refer to Section 8.7.
0 0 1 -
I 51 46
Terminal 46 : DHW Electric heater or Backup heater
0=DHW Electric heater
1=Backup heater
0 0 1 -
* External timer required
For details of how to access the parameter settings, refer to Section 9.3.
9.8 Remote Controller Back Light Display Parameters
The following parameters can be changed to adjust the back light
display.
Table 9-3: Back light display parameters
Level
Parameter
Function description
Display and input value
Remarks
Group Code Default Min. Max. Unit
U 02 03
Back light display at door open
0=OFF
1=ON
1 0 1 -
U 02 04 Time to turn off the back light display 60 10 300 10 sec
U 02 05 Time to back to normal display screen 120 10 300 10 sec
For details of how to access the parameter settings, refer to Section 9.3.
