Grant HPiD6 User Manual

Section 12: Spare Parts Page 61
12.4 Spare Parts List - HPID10
Item Description Product code
1 Outlet grille HPID938106
2 Front panel assembly (left) HPID885767
3 Front panel assembly (right) HPID885768
4 Top panel assembly HPID885504
5 Propeller fan HPID934945
6 Motor HPID885510
7 Bracket (motor) HPID934947
8 Wiring lid HPID885507
9 Back panel assembly HPID885769
10 Bottom panel assembly (without heater) HPID885506
11 Condenser assembly HPID883634
12 Expansion valve HPID885511
13 Coil (expansion valve) HPID884119
14 4-way valve HPID938113
15 Coil (4-way valve) HPID883796
16 Sensor (temperature discharge and suction) HPID937013
17 Sensor (temperature circulating water) HPID885265
18 Sensor (temperature defrost) HPID937014
19 Sensor (temperature outdoor) HPID883780
20 Outdoor thermistor holder HPID937016
21 Heat exchanger assembly HPID885509
22 Pump assembly HPID885512
23 Circulating water pipe assembly HPID885513
24 Circulating water return port HPID885514
25 Bypass pipe assembly HPID885515
26 Drain plug HPID885519
27 Hose coupling 1 assembly (pump inlet) HPID885516
28 Hose coupling 2 assembly (pump outlet) HPID885271
29 Hose coupling 3 (heat exchanger) HPID885272
30 Rubber hose (pump inlet water) HPID885273
31 Rubber hose (pump outlet water) HPID885517
32 Rubber hose (for relief valve) HPID885520
33 Hose band HPID937221
34 Compressor HPID934944
35 Vibration proof rubber HPID934959
36 Reactor HPID885259
37 Terminal block HPID885263
38 Case of PCB (cover) HPID885393
39 Main PCB HPID885501
40 Case of PCB HPID883847
41 Sound proof material 1 HPID883882
42 Sound proof material 2 HPID883883
43 Sound proof material 3 HPID883884
44 Sound proof material 4 HPID883885
45 Sound proof material 5 HPID884582
46 Sound proof material 6 HPID885518
47 Relief valve HPID883798
Item Description Product code
48 Air purge valve HPID885266
49 O-ring (P3) HPID807209
50 O-ring (P4) HPID807207
51 O-ring (P6) HPID807205
52 O-ring (P12.5) HPID808972
53 O-ring (P14) HPID910164
54 O-ring (P16) HPID807213
55 O-ring (P22) HPID922856
56 Quick fastener HPID761569
57 Quick fastener (12.7) HPID790706
58 Quick fastener (16A) HPID963516
59 Quick fastener (16B) HPID884148
60 Quick fastener (sensor temperature water) HPID883848
61 Terminal PCB HPID885254
62 Controller PCB HPID885765
63 Power transformer HPID885264
64 Defrost heater HPID885508
65 Defrost heater holder 1 HPID884163
66 Defrost heater holder 2 HPID884132
70 Fin guard HPID885781
