Grant HPiD6 User Manual

Section 12: Spare Parts Page 59
12.2 Spare Parts List - HPID6
Item Description Product code
1 Outlet grille HPID927368
2 Front panel assembly HPID885766
3 Right side panel HPID883774
4 Left side panel assembly HPID883741
5 Top panel HPID884558
6 Propeller fan HPID922330
7 Motor HPID937022
8 Bracket (motor) HPID937023
9 Sensor (temperature outdoor) HPID883780
11 Bottom panel assembly (without heater) HPID883759
12 Wiring lid assembly HPID937262
13 Condenser assembly HPID883743
14 Coil (expansion valve) HPID937196
15 Expansion valve HPID922928
16 Sensor (temperature defrost) HPID937014
17 Heat exchanger assembly HPID883744
18 Pump assembly HPID885394
20 Compressor HPID937199
21 Vibration proof rubber HPID883782
22 Sensor (temperature discharge/suction) HPID937013
24 Sensor (temperature water) HPID937193
25 Reactor HPID927200
26 Terminal block HPID885263
27 Terminal PCB HPID885254
28 Main PCB HPID885392
29 Rubber hose (for relief valve) HPID883784
33 Sound proof material 1 HPID883791
34 Sound proof material 2 HPID883792
35 Sound proof material 3 HPID883793
36 Sound proof material 4 HPID883794
37 Sound proof material 5 HPID883795
38 Outdoor themistor holder HPID937016
39 Coil - 4-way valve HPID883796
41 Relief valve HPID883798
42 Air purge valve HPID885266
44 4-way valve HPID927359
45 Circulating water flow port assembly HPID884560
46 Circulating water return port assembly HPID883778
47 Rubber hose 1 HPID883786
48 Rubber hose 8 HPID884561
49 Rubber hose 3 HPID885396
50 Rubber hose 4 HPID885397
51 Rubber hose 6 HPID883790
53 O-ring (P3) HPID807209
54 O-ring (P4) HPID807207
55 O-ring (P12.5) HPID808972
56 O-ring (P14) HPID910164
Item Description Product code
57
Quick fastener (for sensor temperature
water)
HPID883848
58 Quick fastener (12.7) HPID790706
60 Hose band A HPID937221
61 Hose band B HPID927535
62 Hose band C HPID934914
65 Drain plug HPID885519
66 Circulating water connection coupling HPID885395
67 Case of PCB HPID883847
68 Case of PCB (cover) HPID885393
69 Defrost heater HPID884211
70 Defrost heater holder 1 HPID884212
71 Defrost heater holder 2 HPID884213
72 Power transformer HPID885264
73 Controller PCB HPID885765
80 Fin guard HPID885782
