Grant HPiD6 User Manual

Section 12: Spare Parts Page 63
12.6 Spare Parts List - HPID16
Item Description Product code
1 Front panel assembly (left) HPID885255
2 Outlet grille HPID938106
3 Front panel assembly (right) HPID885770
4 Top panel assembly HPID884552
5 Back panel assembly (right) HPID885257
6 Wiring lid HPID884129
7 Back panel (left) HPID884126
8 Bottom panel assembly (without heater) HPID885258
9 Reactor HPID885259
10 Motor HPID885260
11 Bracket (motor) HPID885261
12 Propeller fan HPID938112
13 Main PCB assembly HPID885252
14 Terminal block HPID885263
15 Coil (4-way valve) HPID883796
16 Coil (expansion valve) HPID884119
17 Sensor (temperature defrost) HPID937014
18 Sensor (temperature discharge and suction) HPID884139
19 Sensor (temperature outdoor) HPID884140
20 Sensor (temperature water) HPID885265
21 Compressor HPID884116
22 Vibration proof rubber HPID884135
23 Condenser assembly HPID884136
24 4-way valve HPID884117
25 High pressure switch HPID884120
26 Expansion valve HPID884118
27 Circulating water pipe assembly HPID885267
28 Pump assembly HPID885268
29 Heat exchanger assembly HPID885262
30 Drain plug HPID885519
31 Relief valve HPID883798
32 Air purge valve HPID885266
33 Quick fastener (12.7) HPID790706
34 Quick fastener (16A) HPID963516
35 Quick fastener (16B) HPID884148
36 Quick fastener (sensor temperature water) HPID883848
38 Circulating water return port HPID885269
38 Hose coupling 1 assembly (pump input) HPID885270
39 Hose coupling 2 (pump outlet) HPID885271
40 Hose coupling 3 (heat exchanger) HPID885272
41 Rubber hose (pump input) HPID885273
42 Rubber hose (pump outlet) HPID885274
43 Rubber hose (relief valve) HPID934970
45 Hose band HPID937221
46 O-ring (P3) HPID807209
47 O-ring (P4) HPID807207
48 O-ring (P12.5) HPID808972
Item Description Product code
49 O-ring (P14) HPID910164
50 O-ring (P16) HPID807213
51 O-ring (P22) HPID922856
52 Sound proof material 1 HPID884142
53 Sound proof material 2 HPID884143
54 Sound proof material 3 HPID885276
55 Sound proof material 4 HPID885277
56 Drain elbow HPID881618
57 Controller PCB HPID885765
58 Terminal PCB HPID885254
59 Power transformer HPID885264
60 Defrost heater HPID884130
61 Defrost heater holder 1 HPID884131
62 Defrost heater holder 2 HPID884132
63 Rubber hose HPID885275
64 Hose band HPID934914
70 Fin guard - back HPID885779
71 Fin guard - side HPID885780
