(6) To adjust the X-axis deviation, press the
F2
(X=) key and then use the and POSITION
keys to change the numeric value.
To adjust the Y-axis deviation, press the
F4
(Y=) key and then use the and POSITION keys
to change the numeric value.
The displayed value changes in one-unit steps in a range from
-
80 to +80.
Each unit corresponds to 0.05 mm. For example, to correct a deviation of 0.3 mm, enter 6.
(7) When both corrective values are satisfactory, press the ENTER key to register your values.
NOTE
Your PEN WIDTH settings will be retained in the plotter’s internal RAM even while the plotter is
turned off.
