Installation

132 Planning and Installation Manual

Figure 69. Location of gain jumpers on SI-33110 input board. HI-33110 is similar.

Note labelling error:

Some "Base" jumpers have

reversed silkscreening. In all

cases, "Expand Enable" requires

a jumper between pins 1 and 2.
