Planning Guide
68 Planning and Installation Manual
The numbers shown here correspond to the connector numbers used
during router configuration (but not, in most cases, to the actual silk
screen number on the rear panel itself since the silk screen numbers
only run from “1” to “32.”)
In Jupiter-controlled systems, the “Name” corresponds to the “logical
input/output name” and the number corresponds to the “physical”
input/output number.
The next example applies to existing systems where re-arrangement of
cables in a sequential pattern is not practical or desirable:
Notice that I/O numbers conform to the ranges shown in Table 9.
Table 11. DV-33128 protected paths (example of non-sequential numbering)
Primary path Secondary path
Out In Out In
Name No. Name No. Name No. Name No.
AirPP 21 MCPP 12 AirSP 33 MCSP 33
Sat1PP 53 StuAPP 54 Sat1SP 1 StuASP 1
Sat2PP 109 StuBPP 95 Sat2SP 96 StuBSP 64
