English
INNOVATION & TECHNOLOGIE
12
13
* Information for each battery terminal
technical specications
Charger and power supply in general
Display 3.0 „Color TFT LCD Touch Screen
Operating voltage range 11 ... 28 V DC (direct current)
Required car battery 12 or 24 V with at least 60 Ah capacity
Required power supply 12 ... 28V DC with at least 25A
Suggested power supply polaron power supply 12V DC 25A, Order Nr. S2012
Maximum charging power ...
... At 12 V supply voltage 700 W
... At 24 V supply voltage 1400 W
Undervoltage cutoff 10.7V
Safety timer 10 ... 900 mins, off
Weight about 1485 g with Stand
Dimensions (W x D x H) 88.2 x 203.4 x 196,3mm
Connections
Battery ports 2, independently settable
Charging current / power per port 0.1 ... 30 A / max. 560 W at 28 V supply voltage
Discharge currents / power per port 0.1 ... 10 A / max. 60 W
Battery memory per port 20 memories
USB charging port B-Type, 5 V and max. 2.5A Output Power
Balancer port Graupner / EH, 1 ... 8 LiPo / Lilo / LiFe cells
Temperature sensor 10 ... 80 ° C / 50 ... 176 ° F
Charge distribution by default 50% / 50%
Ni-Cd & Ni-MH batteries*
Cell number 1 ... 16 cells | charge, discharge cycle
Charging process automatic, normal, linear
Delta-peak NiCd 5 ... 25 mV / cell, NiMh 3 ... 15 mV / cell
Trickle charging Off, <500 mA, automatic (1/20 of the charge current)
Cycles 1 ... 10 cycles, wait time adjustable 1 ... 30 min
Adjustable Direction Charge → discharge, discharge → charge
Adjustable capacity range 10 ... 150%
Lithium batteries*
Cell number 1 ... 8 cells | Charge, discharge, storage mode
Charging method normal, fast
Cell voltages 3.3V (LiFe), 3.6 V (Lilo) and 3.7 V (LiPo)
Adjustable capacity range 10 ... 120%
Charge rate 1 ... 5C
TCS capacity 10 ... 100%
Balancing current max. 1000 mAh
Lead batteries*
Cell number 1 ... 12 cells | charge, discharge
Cell voltage 2V
