English
INNOVATION & TECHNOLOGIE
16
17
Control buttons
ESC button
Press this button to con rm the current setting and disables the active set-
ting page. In addition, press this button to return to the previous page and
changed data is stored.
DEC button
Press this button to change if necessary one page down or reduce setting
values in the selected  elds.
INC button
Press this button to change if necessary one page up or increase setting
values in the selected  elds.
ENTER but-
ton
Press this button to change if necessary to the nearest side of the display;
start a process or store the entered data.
CPY
CPY button Press this button to copy values or settings.
Push button
on the front
1. With a press of this button changes between CH1 and CH2.
2. Press and hold during power up:
Recall the <Factory Default>, see page 45
Menu PROFILE
In the “PROFILE“ menu you store the data of your batteries and complement them with the re-
spective charge/discharge parameters in the “CHARGE“ and “DISCHARGE“ menus. The data on
the currently active charge channel (CH1 / CH2) are displayed by default for the last battery mem-
ory selected after opening this menu.
To change this selection, you have to tap on the upper “memory location“  eld with your  nger or
with the supplied pen placed in the side of the device. Choose the desired memory location 0 ... 19
in the blue area via the INC / DEC buttons at the bottom of the display. Tapping again the  eld
deactivates the choice.
“Upper” Settings
Field Description
01 “BATTERY
NAME“
Number and name of the selected memory location
Type Battery type (NiCd, NiMH, LiIo, LiPo, LiFe, Pb)
Volt (Voltage) Cell number from type and cell voltage resulting from bat-
tery voltage
Capac. (Capacity) Battery capacity
AM 10:49:30PROFILE
01 BATTERY NAME
Type
Voltage
Capacity
Type
Voltage
Capacity
CPY
NiMH
01s
1.2V
4600 mAh
NiMH
01s
1.2V
4600 mAh
01 BATTERY NAME
