Gree GMV-ND100L/A-T

GREE GMV5 INDOOR UNIT SERVICE MANUAL
13
Model
GMV-
ND56PHS/A-
T
GMV-
ND63PHS/A-
T
GMV-
ND71PHS/A-
T
GMV-ND80
PHS/A-T
GMV-ND90
PHS/A-T
GMV-
ND100PHS/A-T
Drain
pipe
External
diameter
×thickness
mm
Φ20×1.2
Φ20×1.2
Φ20×1.2
Φ20×1.2
Φ20×1.2
Φ20×1.2
Unit Dimensions
(mm)(W×D×H)
mm
1271×558
×268
1271×558
×268
1271×558
×268
1271×558
×268
1229×775
×290
1229×775
×290
Net weight
kg
35
35
35
35
47
47
Model
GMV-
ND112PHS/A
-T
GMV-
ND125PHS/A
-T
GMV-
ND140PHS/A
-T
GMV-
ND160PHS/A
-T
GMV-
ND224PH/A-
T
GMV-
ND280PH/A-
T
Horse Power
HP
4
5
5
6
8
10
Cooling capacity
kW
11.2
12.5
14.0
16.0
22.4
28.0
Heating capacity
kW
12.5
14.0
16.0
17.0
25.0
31.0
Air volume
m
3
/h
1700
2000
2000
2650
4000
4400
Static pressure (Pa)
Standard
70
70
70
70
100
100
Optional
0~100
0~100
0~100
0~150
50~200
50~200
Cooling power input
W
200
220
220
350
800
900
Cooling current input
A
1.0
1.0
1.0
1.5
4.1
4.6
Heating power input
W
200
220
220
350
800
900
Heating current input
A
1.0
1.0
1.0
1.5
4.1
4.6
Minimum line current
A
1.25
1.25
1.25
1.875
6
6
Maximum fuse current
A
6
6
6
10
10
10
Sound pressure level
dB(A)
46
48
48
50
54
55
Power supply
220-240V 1 phase ~50Hz/208-230V 1 phase ~60Hz
Piping
interface
Liquid pipe
mm
Φ9.52
Φ9.52
Φ9.52
Φ9.52
Φ9.52
Φ9.52
Gas pipe
mm
Φ15.9
Φ15.9
Φ15.9
Φ19.05
Φ19.05
Φ22.2
Drain
pipe
External
diameter
×thickness
mm
Φ20×1.2
Φ20×1.2
Φ20×1.2
Φ20×1.2
Φ25×2
Φ25×2
Unit Dimensions
W×D×H
mm
1229×775
×290
1229×775
×290
1229×775
×290
1340×750
×350
1483×791
×385
1686×870
×450
Net weight
kg
47
47
47
60
82
105
Notes:
① Rated cooling capacity test conditions: indoor 27°C DB/19°C WB, outdoor 35°C DB; connection
pipe length: 5 m, without height drop between units.
② Rated heating capacity test conditions: indoor 20°C DB, outdoor 7°C DB/6 °C WB; connection
pipe length: 5 m, without height drop between units.
