Gree GMV-ND100L/A-T

GREE GMV5 INDOOR UNIT SERVICE MANUAL
193
No.
Name of part
For the following unit
For the following unit
Unit
Product Code
Unit
Product Code
GMV-ND224PH/A-T
CM800N3721
GMV-ND280PH/A-T
CM800N3731
Part code
Quantity
Part code
Quantity
18
Strainer
0741410000601
1
0741410000601
1
19
Electronic Expansion Valve
07331139
1
07331139
1
20
filter guide groove
02284107
2
02284105
2
21
Filter Sub-Assy
11725211
2
11724102
2
22
Evaporator Assy
01024100119
1
01024100124
1
23
Hook
02112466
4
02112466
4
24
Top Cover Board Sub-assy
01265359
1
01264215
1
25
Water Tray Assy
01284620
1
01284306
1
26
Choke Plug of Water Pipe
76712454
2
76712454
2
27
Right Side Plate Sub-Assy
01314321
1
01314312
1
28
Right Side Plate Sub-Assy
01314100086'
1
01314100088
1
29
Sensor Sub-assy
39008000103G
1
39008000103G
1
30
Display Board
30296000040
1
30296000040
1
Above data is subject to change without notice, pls reference the SP in global service website.
5.3 Low Static Pressure Duct Type
Exploded View of GMV-ND22PLS/A-T, GMV-ND25PLS/A-T, GMV-ND28PLS/A-T, GMV-ND32PLS/A-
T, GMV-ND36PLS/A-T:
1 2 3 4 5 6 11 12
13
14
1516
1718
19202122232425262728293031
3233
7
8 10
9
35
34
36
