Gree GMV-ND100L/A-T

GREE GMV5 INDOOR UNIT SERVICE MANUAL
15
Model
GMV-
ND63PL
S/A-T
GMV-
ND71PL
S/A-T
GMV-
ND80PL
S/A-T
GMV-
ND90PL
S/A-T
GMV-
ND100P
LS/A-T
GMV-
ND112PL
S/A-T
GMV-
ND125P
LS/A-T
GMV-
ND140P
LS/A-T
Drain pipe
External
diameter
×thickness
mm
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Dimensions
W×D×H
mm
1100
×615×200
1200
×655×260
1200
×655×260
1340
×655×260
1340
×655×260
1340
×655×260
1340
×655×260
1340
×655×260
Net weight
kg
31
40
40
46
46
46
47
47
Notes:
① Rated cooling capacity test conditions: indoor 27°C DB/19°C WB, outdoor 35°C DB; connection
pipe length: 5m, without height drop between units.
② Rated heating capacity test conditions: indoor 20°C DB, outdoor 7°C DB/6 °C WB; connection
pipe length: 5m, without height drop between units.
③ In the column of “Unit external static pressure”: The figure before “/” indicates the default external
static pressure of unit before delivery, and the figures after indicate the adjustable static pressure
range of unit.
3.4 4-way Cassette Type
Model
GMV-
ND28T/A-T
GMV-
ND36T/A-T
GMV-
ND45T/A-T
GMV-
ND50T/A-T
GMV-
ND56T/A-T
GMV-
ND63T/A-T
GMV-
ND71T/A-T
Horse Power
HP
1
1.5
2
2
2
3
3
Cooling capacity
kW
2.8
3.6
4.5
5.0
5.6
6.3
7.1
Heating capacity
kW
3.2
4.0
5.0
5.6
6.3
7.1
8.0
Air volume
m
3
/h
750
750
750
830
1000
1000
1180
Cooling power input
W
48
48
48
50
59
59
68
Cooling current input
A
0.2
0.2
0.2
0.2
0.3
0.3
0.3
Heating power input
W
48
48
48
50
59
59
68
Heating current input
A
0.2
0.2
0.2
0.2
0.3
0.3
0.3
*Minimum line current
A
0.25
0.25
0.25
0.25
0.38
0.38
0.38
*Maximum fuse current
A
6
6
6
6
6
6
6
Sound pressure level
dB(A)
36
36
36
36
37
37
38
Power supply**
220-240V 1 phase ~50Hz/208-230V 1 phase ~60Hz
Piping
interface
Liquid pipe
mm
Φ6.35
Φ6.35
Φ6.35
Φ6.35
Φ9.52
Φ9.52
Φ9.52
Gas pipe
mm
Φ9.52
Φ12.7
Φ12.7
Φ12.7
Φ15.9
Φ15.9
Φ15.9
Drain pipe
External
diameter
×thickness
mm
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Main body
dimensions
W×D×H
mm
840×840
×190
840×840
×190
840×840
×190
840×840
×190
840×840
×240
840×840
×240
840×840
×240
Panel
dimensions
W×D×H
mm
950×
950×65
950×
950×65
950×
950×65
950×
950×65
950×950
×65
950×950
×65
950×950
×65
Net weight
Main body
kg
22.5
22.5
22.5
22.5
26.5
26.5
26.5
Panel
kg
7
7
7
7
7
7
7
