NOTICE
If you cannot find an item on this list, care-
fully check around/inside the machine and
packaging materials. Often, these items get
lost in packaging materials while unpack-
ing or they are pre-installed at the factory.
The following is a list of items shipped with your
machine. Before beginning setup, lay these items
out and inventory them.
If any non-proprietary parts are missing (e.g. a
nut or a washer), we will gladly replace them; or
for the sake of expediency, replacements can be
obtained at your local hardware store.
Box Contents (Figure 6) Qty
A. Pulley Cover ............................................... 1
B. Collar ......................................................... 1
C. Wheels ...................................................... 2
D. Axle ........................................................... 1
E. Leveling Feet with Hex Nuts ..................... 2
F. Chip Screen .............................................. 1
G. Work Stop .................................................. 1
H. Work Stop Rod .......................................... 1
I. Vertical Work Table ................................... 1
J. Table Bracket ............................................ 1
K. V-Belt 3V270 (Not Shown) ........................ 1
Hardware Bag (Not Shown)
• Flat Washers
3
⁄8" (Leveling Feet) ................ 2
• Cotter Pins 3 x 30mm (Wheels) ................. 2
• Flat Washers
5
⁄8" (Wheels) ......................... 4
• Wire Nuts (for 220V Wiring) ........................ 2
• Flat Head Screw
1
⁄4"-20 x
1
⁄2" (Table) .......... 1
• Hex Nut
1
⁄4"-20 (Table) ................................ 1
• Knob
1
⁄4"-20 x
5
⁄8" (Pulley Cover) ................ 1
• Hex Nuts
3
⁄8"-16 .......................................... 2
• Hose Clamp
5
⁄8" (Coolant Hose) ................. 1
• Hex Bolts
5
⁄16"-18 x 1" (Motor) ..................... 4
• Hex Nuts
5
⁄16"-18 (Motor) ............................. 2
• Flat Washers
5
⁄16" (Motor) ........................... 2
Figure 6. Loose parts inventory.
E
D
F
G
H
I
J
A
B
C
Inventory
