-44-
Model G0561 (Mfd. Since 01/08)
Squaring Blade
It is always a good idea during the life of your saw
to check and adjust this setting. This adjustment
will improve your cutting results and extend the
life of your blade.
To square blade to bed of table:
1. DISCONNECT MACHINE FROM POWER!
2. Lower head of the bandsaw until it contacts
horizontal stop.
3. Place a square on table bed and against
edge of blade (see Figure 58), and check
different points along length of table between
blade guides.
Figure 58. Square placed on table bed against
edge of blade.
Cap Screw
4. Loosen cap screw shown in Figure 58, and
rotate blade guide until blade is vertical to
bed.
Note: Both blade guides can be adjusted to
achieve the results you want.
5. Tighten cap screw.
