Grizzly G0561 User Manual

-50-
Model G0561 (Mfd. Since 01/08)
Cabinet & Base Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0561001 BASE 66 P0561066 SWITCH SHUT-OFF TIP
2 P0561002 ACME SCREW 22 X 5 X 480 67 P0561067 HEX BOLT 3/8-16 X 1-1/4
3 P0561003 FLAT WASHER 1/2 68 P0561068 FLAT WASHER 5/16
4 P0561004 KEY 5 X 5 X 15 69 P0561069 HEX NUT 5/16-18
5 P0561005 HANDWHEEL 70 P0561070 SWITCH BRACKET
5-1 P0561005-1 HANDWHEEL HANDLE 71 P0561071 TOGGLE SWITCH COVER
7 P0561007 KNOB BOLT 3/8-16 72 P0561072 HEX BOLT 5/16-18 X 1
8 P0561008 FLAT WASHER 3/8 75 P0561075 PHLP HD SCR 10-24 X 3/8
9 P0561009 VISE JAW, FRONT 77 P0561077 STAND ASSEMBLY
10 P0561010 ROLL PIN 5 X 34 77-1 P0561077-1 STAND SHELF
11 P0561011 BRACKET 78 P0561078 HOSE 12 X 8 X 200MM
12 P0561012 ACME NUT ASSY 22 X 5 82 P0561082 COOLANT TANK
17 P0561017 HEX BOLT 3/8-16 X 1-1/2 83 P0561083 COOLANT PUMP SWITCH CORD 16G 3W 26"
18 P0561018 HEX NUT 1/2-12 84V2 P0561084V2 COOLANT PUMP MOTOR V2.07.09
19 P0561019 FLAT WASHER 1/2 85 P0561085 PHLP HD SCR 1/4-20 X 5/8
20 P0561020 CARRIAGE BOLT 1/2-12 X 2 86 P0561086 FLAT WASHER 1/4
21 P0561021 HEX BOLT 1/2-12 X 2 87 P0561087 COOLANT PUMP CORD 18G 3W 23"
22 P0561022 VISE JAW, REAR 88 P0561088 HOSE COUPLER 3/8 NPT X 5/16
23 P0561023 BUSHING 89 P0561089 HOSE CLIP 5/8"
24 P0561024 SUPPORT ROD 90 P0561090 HOSE 12 X 8 X 2000MM
25 P0561025 HEX BOLT 5/16-18 X 3/4 91 P0561091 VALVE ASSEMBLY
26 P0561026 PIVOT BRACKET 94 P0561094 STAND WHEEL AXLE
27 P0561027 SPRING BRACKET 75 X 25.4 95 P0561095 STAND WHEEL
28 P0561028 HEX BOLT 3/8-16 X 1-1/2 96 P0561096 COTTER PIN 3 X 25MM STANDARD
29 P0561029 SUPPORT PLATE 97 P0561097 CYLINDER ASSEMBLY RF-712N
30 P0561030 FIXED PLATE 99 P0561099 FLAT WASHER 5/16
31 P0561031 TENSION SPRING 32 X 282 100 P0561100 HEX BOLT 5/16-18 X 1
32 P0561032 EYE BOLT 3/8-16 X 4-1/2 101 P0561101 CAP SCREW 3/8-16 X 2-1/4
33 P0561033 SPRING HANDLE BRACKET 102 P0561102 FLAT WASHER 3/8
34 P0561034 HEX BOLT 5/16-18 X 3/4 135 P0561135 FLAT WASHER 5/16
35 P0561035 FLAT WASHER 5/16 136 P0561136 HEX BOLT 5/16-18 X 3/4
36 P0561036 HEX NUT 3/8-16 316 P0561316 SCALE
37 P0561037 FLAT WASHER 3/8 324 P0561324 ELECTRICAL BOX
38 P0561038 LEAF SCREW 5/16-18 325 P0561325 SWITCH COVER
39 P0561039 HEX BOLT 5/16-18 X 3/4 326 P0561326 PHLP HD SCR 10-24 X 3/8
40 P0561040 WORK STOP ROD 333 P0561333 FLAT WASHER #10
41 P0561041 WORK STOP 335 P0561335 STRAIN RELIEF 5/8 NPT NYLON
42 P0561042 HEX BOLT 5/16-18 X 1-1/2 341 P0561341 CYLINDER SUPPORT, LOWER
43 P0561043 HEX NUT 5/16-18 342 P0561342 CYLINDER SUPPORT, UPPER
45 P0561045 SUPPORT PLATE 352 P0561352 FLAT WASHER 5/16
46 P0561046 HEX BOLT 3/8-16 X 1-3/4 353 P0561353 HEX BOLT 5/16-18 X 1/2
47 P0561047 HEX NUT 3/8-16 354 P0561354 SPACER 8 X 16 X 2
48 P0561048 HEX BOLT 5/16-18 X 3/4 355 P0561355 HEX NUT 3/8-16
49 P0561049 FLAT WASHER 5/16 370 P0561370 STRAIN RELIEF 1/2 NPT NYLON
50 P0561050 HEX BOLT 3/8-16 X 1-3/4 393 P0561393 TOGGLE SWITCH KEDU HY29H
51 P0561051 HEX NUT 3/8-16 407 P0561407 CABINET HANDLE
52 P0561052 HEX BOLT 5/16-18 X 3/4 408 P0561408 HEX NUT 5/16-18
53 P0561053 LOCK WASHER 5/16 409 P0561409 FLAT WASHER 5/16
55 P0561055 ELECTRICAL BOX GASKET, RUBBER 410 P0561410 HEX BOLT 5/16-18 X 1-1/4
57V2 P0561057V2 TOGGLE SWITCH KEDU HY29H V2.01.08 411 P0561411 LEVELING FOOT 3/8-16 x 3
59 P0561059 PHLP HD SCR 10-24 X 3/8 420 P0561420 HEX NUT 3/8-16
65 P0561065 DRAIN SCREEN 421 P0561421 FLAT WASHER 3/8
