Model G0561 (Mfd. Since 01/08)
Bow & Motor Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
115 P0561115 PHLP HD SCR M5-.8 X 8 284 P0561284 KNOB BOLT M6-1 X 12
201 P0561201 GEARBOX ASSY 285 P0561285 FLAT WASHER 1/4
203 P0561203 KEY 5 X 5 X 30 286 P0561286 BLADE BACK COVER
204 P0561204 KEY 6 X 6 X 20 288 P0561288 FLAT WASHER 1/4
209-1 P0561209-1 SPINDLE PULLEY 289 P0561289 PHLP HD SCR 1/4-20 X 1/2
209-2 P0561209-2 SET SCREW M6-1 X 10 290 P0561290 KNOB BOLT M10-1.5 X 35
211 P0561211 V-BELT M27 3L270 291 P0561291 MOTOR PULLEY COVER
227 P0561227 BODY FRAME 292 P0561292 SHAFT COVER
228 P0561228 LOCK WASHER 3/8 293 P0561293 HEX BOLT 1/4-20 X 1/2
229 P0561229 HEX BOLT 3/8-16 X 1-1/4 294 P0561294 FLAT WASHER 1/4
230 P0561230 EXT RETAINING RING 25MM 295 P0561295 KEY 5 X 5 X 30
231 P0561231 DRIVE WHEEL 297-1 P0561297-1 MOTOR PULLEY
232 P0561232 HEX BOLT 5/16-18 X 3/4 297-2 P0561297-2 SET SCREW 1/4-20 X 3/8
237 P0561237 SLIDING PLATE 298 P0561298 CARRIAGE BOLT 5/16-18 X 1
238 P0561238 BLADE TENSION SLIDING BLOCK 299 P0561299 HEX BOLT 3/8-16 X 1-1/4
239 P0561239 SET SCREW 5/16-18 X 3/4 300V3 P0561300V3 MOTOR 1HP 115/230V 1-PH V3.01.08
240 P0561240 HEX BOLT 5/16-18 X 1-1/2 300-1V3 P0561300-1V3 MOTOR FAN COVER, PLASTIC V3.01.08
241 P0561241 FLAT WASHER 5/16 300-2 P0561300-2 MOTOR FAN
242 P0561242 LOCK WASHER 5/16 300-3 P0561300-3 CAPACITOR COVER
243 P0561243 HEX BOLT 5/16-18 X 3/4 300-4 P0561300-4 CAPACITOR 400MFD 125VAC
244 P0561244 COMPRESSION SPRING 115 X 4 300-5V3 P0561300-5V3 JUNCTION BOX V3.01.08
245 P0561245 KNOB BOLT M10-1.5 X 50 300-6 P0561300-6 CIRCUIT BREAKER 13A
249 P0561249 WHEEL SHAFT ASSEMBLY 301 P0561301 HEX BOLT 5/16-18 X 1-1/2
250 P0561250 IDLER WHEEL 302 P0561302 HEX NUT 5/16-18
251 P0561251 BLADE 0.032 X 3/4 X 93 X 8T 303 P0561303 MOTOR MOUNT
254 P0561254 SWITCH SHUT-OFF LATCH 304 P0561304 HEX NUT 5/16-18
255 P0561255 FLAT WASHER 1/4 305 P0561305 HEX BOLT 5/16-18 X 3/4
256 P0561256 PHLP HD SCR 1/4-20 X 1/2 306 P0561306 FLAT WASHER 5/16
258 P0561258 BRUSH ASSEMBLY 307 P0561307 MOTOR MOUNT BRACKET
258-1 P0561258-1 BRUSH 308 P0561308 FLAT WASHER 3/8
261 P0561261 KNOB BOLT M10-1.5 X 35 310 P0561310 PHLP HD SCR 1/4-20 X 1/2
266 P0561266 ADJUST BRACKET, REAR 311 P0561311 FLAT WASHER 1/4
267 P0561267 GUIDE PIVOT ASSEMBLY 312 P0561312 SUPPORT PLATE
267-1 P0561267-1 DEFLECTOR PLATE 313 P0561313 VERTICAL SAW TABLE
268 P0561268 BEARING SHAFT ASSY, REAR 313-1 P0561313-1 TABLE BRACKET
269 P0561269 ADJUST BRACKET, FRONT 314 P0561314 FLAT WASHER 3/8
270 P0561270 GUIDE PIVOT ASSEMBLY 317 P0561317 POWER CORD 14G 3W 84" 5-15 V3.01.08
271 P0561271 BEARING SHAFT ASSY, FRONT 318 P0561318 POWER SWITCH CORD 14G 3W 54"
279 P0561279 BLADE COVER, FRONT 357 P0561357 FLAT WASHER 5/16
280 P0561280 PHLP HD SCR 8-32 X 1/4 358 P0561358 HEX BOLT 5/16-18 X 1
