Grizzly G0704 User Manual

-48-
Model G0704 (Mfg. Since 08/11)
Column Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0704001 Z-AXIS SLIDE 39 P0704039 SPRING PIECE
2 P0704002 SET SCREW M6-1 X 16 40 P0704040 HEX NUT M8-1.25
3 P0704003 FLAT WASHER 8MM 41 P0704041 Z-AXIS HANDWHEEL HANDLE M6-1 X 10
4 P0704004 LOCK WASHER 8MM 42 P0704042 BALL BEARING 6001ZZ
5 P0704005 CAP SCREW M8-1.25 X 25 43 P0704043 Z-AXIS HANDWHEEL SHAFT
6 P0704006 FLAT WASHER 12MM 44 P0704044 KEY 4 X 4 X 12
7 P0704007 LOCK WASHER 12MM 45 P0704045 PILLOW BLOCK
8 P0704008 CAP SCREW M12-1.75 X 40 46 P0704046 SPACER
9 P0704009 T-BOLT M10-1.5 47 P0704047 PINION GEAR
10 P0704010 FLAT WASHER 10MM 48 P0704048 COLUMN
11 P0704011 LOCK WASHER 10MM 49 P0704049 Z-AXIS SCALE
12 P0704012 HEX NUT M10-1.5 50 P0704050 THREADED SLEEVE M6-1 X 16
13 P0704013 SLIDE ALIGNMENT BLOCK 51 P0704051 CAP SCREW M6-1 X 14
14 P0704014 LOCK PLUNGER, BRASS 52 P0704052 X-AXIS LEADSCREW BRACKET (LH)
15 P0704015 ADJUSTABLE HANDLE M8-1.25 X 20 54 P0704054 TABLE
16 P0704016 GIB ADJUSTMENT SCREW 55 P0704055 COOLANT HOSE FITTING
17 P0704017 Z-AXIS GIB 56 P0704056 X-AXIS LEADSCREW BRACKET (RH)
18 P0704018 HEADSTOCK ANGLE SCALE 57 P0704057 TABLE HANDWHEEL HANDLE M6-1 X 10
19 P0704019 CAP SCREW M5-.8 X 10 58 P0704058 TABLE HANDWHEEL
20 P0704020 Z-AXIS WAY COVER 59 P0704059 TABLE GRADUATED DIAL
21 P0704021 HEX NUT M5-.8 60 P0704060 THRUST BEARING 51200
22 P0704022 Z-AXIS WAY COVER BRACKET 61 P0704061 CAP SCREW M6-1 X 10
23 P0704023 Y-AXIS WAY COVER 62 P0704062 LIMIT STOP
24 P0704024 Y-AXIS WAY COVER BRACKET 63 P0704063 T-NUT M6-1
25 P0704025 Z-AXIS LEADSCREW LOCK NUT 64 P0704064 X-AXIS SCALE
26 P0704026 THRUST BEARING 51203 65 P0704065 X-AXIS LEADSCREW
27 P0704027 BEVEL GEAR 66 P0704066 X-AXIS LEADSCREW NUT
28 P0704028 KEY 4 X 4 X 16 67 P0704067 CAP SCREW M4-.7 X 20
29 P0704029 Z-AXIS LEADSCREW 68 P0704068 SADDLE
30 P0704030 Z-AXIS LEADSCREW NUT 69 P0704069 TABLE STOP BLOCK
31 P0704031 CAP SCREW M5-.8 X 12 70 P0704070 Y-AXIS GIB
31-1 P0704031-1 FLAT WASHER 5MM 71 P0704071 Y-AXIS LEADSCREW NUT
32 P0704032 BEARING COVER 72 P0704072 X-AXIS GIB
33 P0704033 CAP SCREW M8-1.25 X 20 73 P0704073 CAP SCREW M6-1 X 25
34 P0704034 COLUMN TOP PLATE 74 P0704074 X-AXIS BEARING HOUSING
35 P0704035 COLLAR FLANGE 75 P0704075 X-AXIS LEADSCREW
36 P0704036 CAP SCREW M5-.8 X 12 76 P0704076 BASE
37 P0704037 Z-AXIS GRADUATED DIAL 77 P0704077 CAP SCREW M12-1.75 X 90
38 P0704038 Z-AXIS HANDWHEEL

Grizzly G0704 Specifications

General

Motor	1 HP, 110V, Single-phase
Spindle Taper	R-8
Max Spindle Speed	2500 RPM
Model	G0704
Category	Drill
Spindle Travel	2"
Spindle Speed	50-2500 RPM
Table Tilt	45° Left/Right
Speed Range	50-2500 RPM
