Grizzly G0704 User Manual

Model G0704 (Mfg. Since 08/11)
-53-
Safety labels warn about machine hazards and ways to prevent injury. The owner of this machine
MUST maintain the original location and readability of the labels on the machine. If any label is
removed or becomes unreadable, REPLACE that label before using the machine again. Contact
Grizzly at (800) 523-4777 or www.grizzly.com to order new labels.
301
310
302
303
304
305
306
307
308
309
REF PART # DESCRIPTION REF PART # DESCRIPTION
301 P0704301 READ MANUAL LABEL 306 P0704306 MODEL NUMBER LABEL
302 P0704302 SAFETY GLASSES LABEL 307 P0704307 GREEN TOUCH-UP PAINT
303 P0704303 MACHINE ID LABEL 308 P0704308 CUTTER WARNING LABEL
304 P0704304 HIGH/LOW SPEED LABEL 309 P0704309 ENTANGLEMENT LABEL
305 P0704305 PUTTY TOUCH-UP PAINT 310 P0704310 AVOID OVERHEATING LABEL
Labels Breakdown & Parts List

Grizzly G0704 Specifications

General

Motor	1 HP, 110V, Single-phase
Spindle Taper	R-8
Max Spindle Speed	2500 RPM
Model	G0704
Category	Drill
Spindle Travel	2"
Spindle Speed	50-2500 RPM
Table Tilt	45° Left/Right
Speed Range	50-2500 RPM
