Grizzly G0817 User Manual

-76-
Model G0817 (Mfd. Since 05/16)
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0817001 DOOR SEAL 10 X 760 X 1MM 41 P0817041 ON BUTTON YIAN KUANG YS-F1-G
2 P0817002 CAP SCREW M6-1 X 20 42 P0817042 OFF BUTTON YIAN KUANG YS-K1
3 P0817003 BUSHING 43 P0817043 SWITCH PLATE
4 P0817004 EYE BOLT M10-1.5 44 P0817044 CAP SCREW M8-1.25 X 16
5 P0817005 MACHINE BODY 45 P0817045 FENDER WASHER 8MM
6 P0817006 E-CLIP 15MM 46 P0817046 UPPER WHEEL SLIDING BRACKET
7 P0817007 TABLE TILT STOP BRACKET 47 P0817047 CAP SCREW M6-1 X 50
8 P0817008 FLAT WASHER 6MM 48 P0817048 RIVET 3.2 X 10 BLIND
9 P0817009 PHLP HD SCR M5-.8 X 8 49 P0817049 CAP SCREW M6-1 X 10
10 P0817010 HEX NUT M6-1 50 P0817050 CLEAR WINDOW 90 X 70 X 3MM
11 P0817011 POINTER 54 P0817054 LOCK NUT M8-1.25
12 P0817012 SHOULDER SCREW M4-.7 X 5, 6 X 3 55 P0817055 UPPER WHEEL COVER
13 P0817013 UPPER BLADE PIVOT SHAFT 56 P0817056 HEX BOLT M6-1 X 25
14 P0817014 ROLL PIN 5 X 36 57 P0817057 FLAT WASHER 6MM
15 P0817015 UPPER WHEEL SHAFT BLOCK 58 P0817058 WHEEL BRUSH 1-3/4"
16 P0817016 UPPER WHEEL SHAFT 59 P0817059 CAP SCREW M6-1 X 25
17 P0817017 LOCK NUT M8-1.25 60 P0817060 LOCK KNOB 60MM DIA
18 P0817018 CAP SCREW M6-1 X 12 61 P0817061 LOCK NUT M6-1
19 P0817019 UPPER WHEEL ASSEMBLY 62 P0817062 STRAIN RELIEF TYPE-3 PG13.5
19-1 P0817019-1 UPPER WHEEL 14" 63 P0817063 GUIDE POST HEIGHT INDICATOR
19-2 P0817019-2 WHEEL TIRE 64 P0817064 HEX NUT M8-1.25
19-3 P0817019-3 BALL BEARING 6202LLU 65 P0817065 HEX BOLT M8-1.25 X 35
19-4 P0817019-4 INT RETAINING RING 35MM 66 P0817066 KNOB BOLT 6-LOBE M10-1.5 X 20
19-5 P0817019-5 BUSHING 67 P0817067 KNOB BOLT 6-LOBE M10-1.5 X 53
20 P0817020 CAP SCREW M10-1.5 X 35 68 P0817068 LOCK LEVER M10-1.5
21 P0817021 FENDER WASHER 8MM 69 P0817069 CAM
22 P0817022 CAP SCREW M8-1.25 X 16 70 P0817070 BLADE TENSION PILLOW BLOCK
23 P0817023 SAW BLADE 120" X 3/8" 6-TPI HOOK 71 P0817071 HANDLE M12-1.75, 26 X 85
24 P0817024 LOCK WASHER 8MM 72 P0817072 STUD-DE M12-1.75 X 240, 30
25 P0817025 SPARE BLADE HOLDER 73 P0817073 HEX NUT M12-1.75
26 P0817026 FLAT WASHER 10MM 74 P0817074 LEVER HUB
27 P0817027 LOWER WHEEL ASSEMBLY 75 P0817075 BUTTON HD CAP SCR M8-1.25 X 20
27-1 P0817027-1 LOWER WHEEL 14" 76 P0817076 LOCK WASHER 8MM
27-2 P0817027-2 WHEEL TIRE 77 P0817077 HANDLE M8-1.25 X 20, 30 X 78L
27-3 P0817027-3 BALL BEARING 6202LLU 78 P0817078 DOCK WASHER 8 X 45 X 5
27-4 P0817027-4 INT RETAINING RING 35MM 79 P0817079 SET SCREW M8-1.25 X 20
27-5 P0817027-5 BUSHING 80 P0817080 HEX NUT M8-1.25
27-6 P0817027-6 WHEEL PULLEY 81 P0817081 LOWER WHEEL SHAFT
27-7 P0817027-7 BUTTON HD CAP SCR M6-1 X 25 82 P0817082 MOTOR 2HP 110V/220V 1-PH
27-8 P0817027-8 LOCK WASHER 6MM 82-1 P0817082-1 MOTOR FAN COVER
28 P0817028 PHLP HD SCR M4-.7 X 8 82-2 P0817082-2 MOTOR FAN
29 P0817029 SPACER 82-3 P0817082-3 S CAPACITOR COVER
30 P0817030 LOWER WHEEL COVER 82-4 P0817082-4 S CAPACITOR 200M 250V 1-3/4 X 4
31 P0817031 SWITCH CORD 16G 1W 7.9" 82-5 P0817082-5 R CAPACITOR COVER
32 P0817032 COMPRESSION SPRING 7 X 34 X 90 82-6 P0817082-6 R CAPACITOR 50M 250V 1-5/8 X 3-3/4
33 P0817033 ROLL PIN 3 X 16 82-7 P0817082-7 MOTOR JUNCTION BOX
34 P0817034 ALIGNMENT PLATE 82-8 P0817082-8 CONTACT PLATE
35 P0817035 THRUST BEARING 51201 82-9 P0817082-9 CENTRIFUGAL SWITCH 1720 RPM
36 P0817036 SET SCREW M8-1.25 X 30 82-10 P0817082-10 BALL BEARING 6205ZZ (FRONT)
37 P0817037 HANDWHEEL TYPE-4 140D X 10B-S 82-11 P0817082-11 BALL BEARING 6203ZZ (REAR)
38 P0817038 BLADE TENSION ADJUSTING ROD 83 P0817083 ADJUSTABLE HANDLE M10-1.5 X 35
39 P0817039 BUTTON HD CAP SCR M5-.8 X 8 84 P0817084 LOCK WASHER 10MM
40 P0817040 KEYED SWITCH YIAN KUANG YS-K1 85 P0817085 MOTOR MOUNT BRACKET
Main Parts List
