Grizzly G0817 User Manual

Model G0817 (Mfd. Since 05/16)
-79-
REF PART # DESCRIPTION REF PART # DESCRIPTION
51 P0817051 MAGNET STRIP 7 X 340MM 144-6 P0817144-6 BEARING BUSHING
52 P0817052 GUARD CLEAR WINDOW 144-7 P0817144-7 CAP SCREW M6-1 X 35
53 P0817053 SET SCREW M4-.7 X 4 146 P0817146 TRUNNION SUPPORT ASSEMBLY
94 P0817094 SET SCREW M8-1.25 X 6 146-1 P0817146-1 FLAT WASHER 8MM
97 P0817097 TABLE END BRACKET 146-2 P0817146-2 LOCK NUT M8-1.25
98 P0817098 CAP SCREW M10-1.5 X 35 146-3 P0817146-3 PHLP HD SCR M4-.7 X 6
103 P0817103 LOCK WASHER 10MM 146-4 P0817146-4 GEAR PLATE
104 P0817104 FLAT WASHER 10MM 146-5 P0817146-5 FLAT HD SCR M4-.7 X 6
126 P0817126 TABLE 146-6 P0817146-6 CARRIAGE BOLT M8-1.25 X 85
127 P0817127 TABLE INSERT 146-7 P0817146-7 TRUNNION BLOCK
128 P0817128 ADJUSTABLE HANDLE M8-1.25 X 35, 76L 146-9 P0817146-9 ADJ HANDLE M8-1.25, 100L
131 P0817131 BUTTON HD CAP SCR M8-1.25 X 20 146-10 P0817146-10 ANGLE SCALE
132 P0817132 LOCK WASHER 8MM 146-13 P0817146-13 ADJ HANDLE M8-1.25 X 85, 100L
133 P0817133 GUIDE POST ASSEMBLY 146-14 P0817146-14 FLAT WASHER 4MM
135 P0817135 CAP SCREW M5-.8 X 12 146-15 P0817146-15 POINTER
136 P0817136 FLAT WASHER 5MM 146-16 P0817146-16 LOCK WASHER 8MM
137 P0817137 BLADE COVER 146-17 P0817146-17 STAR KNOB BOLT M6-1 X 50
138 P0817138 FLAT WASHER 8MM 146-18 P0817146-18 HEX NUT M6-1
139 P0817139 LOCK WASHER 8MM 146-19 P0817146-19 TENSION PLATE
140 P0817140 HEX BOLT M8-1.25 X 25 146-20 P0817146-20 FLANGE SCREW M5-.8 X 8
141 P0817141 HANDWHEEL TYPE-4 140D X 10B-S 146-21 P0817146-21 CAP SCREW M6-1 X 16
142 P0817142 CAP SCREW M6-1 X 20 146-22 P0817146-22 CAP SCREW M6-1 X 50
143 P0817143 UPPER BLADE GUIDE ASSEMBLY 146-23 P0817146-23 TRUNNION SUPPORT BRACKET
143-1 P0817143-1 CAP SCREW M6-1 X 12 146-24 P0817146-24 TRUNNION GEAR
143-2 P0817143-2 UPPER BLADE GUIDE SUPPORT BLOCK 146-25 P0817146-25 BUTTON HD CAP SCR M10-1.5 X 30
143-3 P0817143-3 UPPER GUIDE ADJUSTMENT SHAFT 146-26 P0817146-26 SUPPORT BEARING COVER (R)
143-4 P0817143-4 UPPER BLADE GUIDE MOUNTING BLOCK 146-27 P0817146-27 BALL BEARING 6000ZZ
143-5 P0817143-5 ECCENTRIC SHAFT 146-28 P0817146-28 FLAT WASHER 10MM
143-6 P0817143-6 EXT RETAINING RING 15MM 146-29 P0817146-29 SUPPORT BEARING COVER (L)
143-7 P0817143-7 BALL BEARING 6202ZZ 146-30 P0817146-30 LOWER SUPPORT ADJUSTMENT SHAFT
143-8 P0817143-8 BEARING BUSHING 146-32 P0817146-32 CAP SCREW M5-.8 X 6
143-9 P0817143-9 CAP SCREW M6-1 X 35 146-33 P0817146-33 LOCK WASHER 10MM
143-10 P0817143-10 UPPER SUPPORT BEARING ADJ SHAFT 146-34 P0817146-34 FLAT WASHER 6MM
143-11 P0817143-11 SET SCREW M6-1 X 10 147 P0817147 FLAT WASHER 8MM
144 P0817144 LOWER BLADE GUIDE ASSEMBLY 148 P0817148 FLAT WASHER 6MM
144-1 P0817144-1 LOWER BLADE GUIDE MOUNTING BLOCK 149 P0817149 FLAT WASHER 8MM
144-2 P0817144-2 CAP SCREW M6-1 X 16 150 P0817150 CAP SCREW M6-1 X 12
144-3 P0817144-3 ECCENTRIC SHAFT 151 P0817151 HEX NUT M8-1.25
144-4 P0817144-4 EXT RETAINING RING 15MM 153 P0817153 FLAT WASHER 8MM
144-5 P0817144-5 BALL BEARING 6202ZZ 154 P0817154 HEX BOLT M10-1.5 X 35
Table, Trunnion, & Blade Guides Parts List
