Grizzly G4002 User Manual

-38-
Model G4003 (Mfd. Since 6/20)
READ ELECTRICAL SAFETY
ON PAGE 36!
Motor & Control Panel Wiring Diagram
Ground
Ground
220V
Motor
Control Panel
6-15 Plug
(As Recommended)
Spindle Switch
Run
Capacitor
20MFD
450VAC
Start
Capacitor
150MFD
250VAC
U2
PE
Z2
U1
Z1
X1 X2
Stop Button
Power Button
Jog Button
Power Lamp
To
Electrical
Cabinet
To
Electrical
Cabinet
To
Electrical
Cabinet
To
Electrical
Cabinet
1
2
3
4
0
0
5
6
2
2
Lb
PE
Hot
Hot
Ground
220
VAC
G
C
C
NO
NO
NC
NC
4
5
7
6
