Grizzly G4002 User Manual

Model G4003 (Mfd. Since 6/20)
-41-
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
Headstock Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
101 P4003101 CAP SCREW M6-1 X 25 154 P4003154 WASHER
102 P4003102 COVER 155 P4003155 GEAR 40T
103 P4003103 OIL SEAL 156 P4003156 KEY CS X 8
104 P4003104 SPINDLE 16" 157 P4003157 OIL SEAL 25 X 40 X 10 V1.10.96
105 P4003105 BEARING D-7212 158 P4003158 EXT RETAINI NG RI NG 20MM
106 P4003106 KEY 8 X 8 X 80 159 P4003159 I NT RETAI NI NG RING 40MM
107 P4003107 KEY 160 P4003160 BALL BEARING 6004 OPEN
108 P4003108 CAP SCREW M3-.5 X 8 161 P4003161 CAP SCREW M6-1 X 12
109 P4003109 GEAR 37T/74T 162 P4003162 OIL SEAL
110 P4003110 GEAR 46T 163 P4003163 COVER
111 P4003111 GEAR 59T 164 P4003164 COLLAR
112 P4003112 NUT 58OD 165 P4003165 SHAFT 117MM
113 P4003113 CAP SCREW M8-1.25 X 10 166 P4003166 KEY 5 X 5 X 20
114 P4003114 ROLL PIN 5 X 40 167 P4003167 GEAR
115 P4003115 COLLAR 168 P4003168 SHAFT
116 P4003116 CAP SCREW M3-.5 X 8 169 P4003169 OIL SEAL 17 X 2.65
117 P4003117 GEAR 170 P4003170 SET SCREW M8-1.25 X 6
118 P4003118 BEARING D-7211 171 P4003171 C-CLIP
119 P4003119 NUT 172 P4003172 I NT RETAI NI NG RING 47MM
120 P4003120 OIL SEAL 173 P4003173 BALL BEARING 6204 OPEN
121 P4003121 COVER 174 P4003174 GEAR 38T/45T
122 P4003122 CAP SCREW M8-1.25 X 20 175 P4003175 LOCK PIN
123 P4003123 CAP SCREW M6-1 X 12 176 P4003176 SPRING 6 X 4 X 22
124 P4003124 COVER 177 P4003177 CAP SCREW M8-1.25 X 16
125 P4003125 OIL SEAL 178 P4003178 ECCENTRIC SHAFT
126 P4003126 BALL BEARING 6304 ZZ 179 P4003179 GEAR
127V2 P4003127V2 SHAFT 219MM V2.01.03 180 P4003180 SET SCREW M8-1.25 X 10
128 P4003128 KEY 8 X 180 181 P4003181 ROLL PIN 6 X 5
129 P4003129 CAP SCREW M3-.5 X 8 182 P4003182 SHAFT
130 P4003130 GEAR 183 P4003183 OIL SEAL
131 P4003131 GEAR 184 P4003184 SHAFT ARM
132 P4003132 GEAR 185 P4003185 C-CLIP
133 P4003133 I NT RETAI NI NG RING 15MM 186 P4003186 CAP SCREW M8-1.25 X 16
134 P4003134 GEAR 187 P4003187 HEX NUT M8-1.25
135 P4003135 GEAR 188 P4003188 SIGN BOARD
136 P4003136 GEAR 189 P4003189 SET SCREW M8-1.25 X 8
137 P4003137 BALL BEARING 6004 OPEN 190 P4003190 COMPRESSIONSPRING 1.2 X 48 X 27
138 P4003138 OIL SEAL 191 P4003191 STEEL BALL 6MM
139V2 P4003139V2 COVER 45MM V2.01.03 192 P4003192 SET SCREW M6-1 X 20
140 P4003140 CAP SCREW M8-1.25 X 20 193V2 P4003193V2 COVER 10-3/8" V2.01.03
141 P4003141 WASHER 194 P4003194 SCREW
142 P4003142 PULLEY 195 P4003195 CAP SCREW M6-1 X 25
143 P4003143 CAP SCREW M6-1 X 12 196V2 P4003196V2 OIL SEAL V2.09.05
144 P4003144 COVER 197V2 P4003197V2 HEADSTOCK V2.01.03
145 P4003145 OIL SEAL 198 P4003198 SHAFT
146 P4003146 GEAR 199 P4003199 COLLAR
147 P4003147 GEAR 1100 P40031100 SHIFTER ARM
148 P4003148 GEAR 1101 P40031101 SHIFTER
149V2 P4003149V2 SHAFT 178MM V2.01.03 1102 P40031102 STEEL FLUTED RIVET 2 X 5MM
150 P4003150 KEY CS X 80 1103 P40031103 NAME PLATE
151 P4003151 KEY 5 X 5 X 80 1104 P40031104 OIL WI NDOW 12MM
152 P4003152 BALL BEARING 6004 OPEN 1104B P40031104B O-RING 15 X 2.65
153 P4003153 CAP SCREW M6-1 X 12 1105 P40031105 CAP SCREW M8-1.25 X 30
