Model G4003 (Mfd. Since 6/20)
-45-
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
REF PART # DESCRIPTION REF PART # DESCRIPTION
301 P4003301 LEADSCREW 337 P4003337 GEAR 16T
302 P4003302 ROLL PIN 5 X 36 342 P4003342 COMBO GEAR 3PC SET
304 P4003304 THRUST BEARING 8103 344 P4003344 GEAR 16T
305 P4003305 SHAFT 345 P4003345 GEAR 18T
306 P4003306 KEY 5 X 5 X 14 346 P4003346 GEAR 19T
308 P4003308 GEAR 347 P4003347 GEAR 20T
309 P4003309 HEX NUT M12-1.75 348 P4003348 GEAR 22T
310 P4003310 WASHER 349 P4003349 GEAR 24T
311 P4003311 CAP SCREW M6-1 X 16 350 P4003350 GEAR 26T
312 P4003312 COVER 351 P4003351 GEAR 28T
313 P4003313 KEY 5 X 5 X 30 352 P4003352 GEAR 24T
314 P4003314 KEY 5 X 5 X 10 353 P4003353 SHAFT
315 P4003315 SHAFT 354 P4003354 KEY 5 X 5 X 75
316 P4003316 BUSHING 355 P4003355 KEY 5 X 5 X 40
318 P4003318 GEAR 16T/32T 356 P4003356 BEARING 7000102
320 P4003320 GEAR 16T/32T 357 P4003357 GEAR 16T
322 P4003322 LEVER 358 P4003358 GEAR 32T W/BUSHING
323 P4003323
FEED ROD
359 P4003359 SHIFT LEVER
324 P4003324 HEX BOLT M10-1.5 X 30 362 P4003362 KEY
325 P4003325 BOSS 363 P4003363 SHAFT
326 P4003326 ROLL PIN 5 X 40 364 P4003364 HEX NUT M6-1
327 P4003327 GEAR BOX 365 P4003365 SHAFT 16MM X 32MM
328 P4003328 PLATE 366 P4003366 SHAFT
329 P4003329 CAP SCREW M6-1 X 16 367 P4003367 COMPRESSION SPRING 1 X 8 X 47
330 P4003330 SHAFT 368 P4003368 SLEEVE
331 P4003331 E-CLIP 13MM 369 P4003369 HOUSING
332 P4003332 SHIFT PIVOT 370 P4003370 SHAFT
333 P4003333 PIN 4 X 30 371 P4003371 CAP SCREW M8-1.25 X 8
334 P4003334 SHIFT YOKE 372 P4003372 GEAR 15T
335 P4003335 CAP SCREW M6-1 X 12 373 P4003373 GEAR 24T
336 P4003336 WASHER 374 P4003374 SHAFT
Quick Change Gearbox Parts List
