Grizzly G4002 User Manual

Model G4003 (Mfd. Since 6/20)
-47-
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
REF PART # DESCRIPTION REF PART # DESCRIPTION
401V2 P4003401V2 HANDLE V2.08.12 437 P4003437 SAFETY SHIFTER
402V2 P4003402V2 HANDWHEEL V2.08.12 438 P4003438 CAP SCREW M8-1.25 X 6
403V2 P4003403V2 GRADUATED DIAL V2.08.12 439 P4003439 COMPRESSION SPRING 1 X 4.5 X 6
404V2 PSS03M SET SCREW M6-1 X 8 440 P4003440 STEEL BALL 6MM
405 P4003405 CAP SCREW M6-1 X 20 441 P4003441 BOSS
406 P4002406 BRACKET 442 P4003442 ROLL PIN 6 X 40
407V2 P4003407V2 GEAR SHAFT V2.08.12 443 P4003443 DOG
408 P4003408 BUSHING 444 P4003444 CAP SCREW M8-1.25 X 30
409 P4003409 ROLL PIN 5 X 30 445 P4003445 LEVER
410 P4003410 GEAR 50T 447 P4003447 SHAFT
411 P4003411 EXT RETAINI NG RI NG 19MM 448 P4003448 CAP SCREW M6-1 X 65
412 P4003412 GEAR SHAFT 449 P4003449 CAP SCREW M6-1 X 15
413 P4003413 GEAR 46T 450 P4003450 GEAR 16T
414 P4003414 GEAR 51T 451 P4003451 CAP SCREW M6-1 X 60
415 P4003415 ROLL PIN 5 X 30 451-2 P4003451-2 SPACER
417 P4003417 SHAFT 452 P4003452 HOUSING
418 P4003418 BUSHING 453 P4003453 THREAD DIAL
419-2 P4003419-2 GEAR W/BUSHING AND SPACER 454 P4003454 HEX NUT M6-1
420 P4003420 SHAFT 455 P4003455 HEX BOLT M6-1 X 16
421 P4003421 WORM 456 P4003456 HALF NUT 2 PC
422 P4003422 KEY 5 X 5 X 45 457 P4003457 HALF NUT HOUSI NG 2 PC
423 P4003423 ROLL PIN 5 X 24 458 P4003458 CAP SCREW M6-1 X 25
424 P4003424 GEAR 14T 459 P4003459 GIB
425 P4003425 BUSHI NG 461 P4003461 SHAFT
426 P4003426 GEAR SHAFT B5 X 36 463 P4003463 GEAR 25T
427 P4003427 LEVER 464 P4003464 SET SCREW M6-1 X 6
428 P4003428 ROLL PIN 5 X 24 465 P4003465 APRON CASE
429 P4003429 STEEL BALL 6MM 466 P4003466 WORM BRACKET
430 P4003430 COMPRESSION SPRING 1 X 4.5 X 6 467 P4003467 LIMIT BLOCK
431 P4003431 SET SCREW M6-1 X 8 468 P4003468 OIL PLUG M10-1.5 X 20
432 P4003432 CAP SCREW M6-1 X 45 469 P4003469 SET SCREW M6-1 X 20
433 P4003433 BOSS 470 P4003470 SPANNER CAP SCREW
434 P4003434 WASHER 471 P4003471 KEY 5 X 5 X 20
435 P4003435 CAP SCREW M6-1 X 40 1104 P40031104 OI L WI NDOW 12MM
436 P4003436 SHAFT
Apron Parts List
