Tailstock Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
701 P4003701 CENTER 715 P4003715 HEX NUT M12-1.75
702 P4003702 KEY 8 X 30 716 P4003716 HANDLE
703 P4003703 QUILL 717 P4003717 LOCK SCREW
704 P4003704 TAIL STOCK 718 P4003718 LOCK SHAFT
705 P4003705 BASE 719 P4003719 HANDLE
706 P4003706 CAP SCREW M10-1.5 X 50 720 P4003720 SHAFT
707 P4003707 SCREW 721 P4003721 ROLL PIN 5 X 30
708 P4003708 PIN B4 X 8 722 P4003722 COLLAR
709 P4003709 THRUST BEARING 8101 723 P4003723 SHAFT
710 P4003710 BRACKET 724 P4003724 BASE SHOE BLOCK
711 P4003711 I NDEX RING 725 P4003725 FLAT WASHER 12MM
712 P4003712 CAP SCREW M6-1 X 20 726 P4003726 HEX NUT M12-1.75
713 P4003713 HAND WHEEL 727 P4003727 NUT
714 P4003714 HANDLE 728 P4003728 I NDEX
