Model T33903/T33904 (Mfd. Since 07/23)
-3-
Identification
Become familiar with the names and locations of the controls and features shown below to better understand
the instructions in this manual.
For Your Own Safety Read Instruction Manual Before Operating Drill Press
a) Wear eye protection.
b) Do not wear gloves, necktie, or loose clothing.
c) Clamp workpiece or brace against column to prevent rotation.
d) Use recommended speed for drill accessory and workpiece material.
Chuck Guard
Motor
Belt Cover
Base
Column
Table
Chuck
Table Height
Crank
ON/OFF Switch
w/Disabling Key
Downfeed
Handle
(1 of 3)
Depth Stop
Belt
Tension
Lock
(1 of 2)
Spindle
Return
Spring
Belt
Tension
Lever
LED &
Laser Guide
Laser & LED
Switches
Table Height
Lock Handle
Table Pivot
Lock Handle
(T33903)
To Next Page
