-56-
Model T33903/T33904 (Mfd. Since 07/23)
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
202
To reduce risk of death
or serious injury, read
manual BEFORE using
machine.
To get a new manual, call
(800) 523-4777 or go to
www.grizzly.com.
WARNING!
INJURY/SHOCK
HAZARD!
Disconnect power
before adjustments,
maintenance, or
service.
WARNING!
WARNING!
Always wear
ANSI-approved safety
glasses and face
shield when using this
machine.
EYE/FACE INJURY
HAZARD!
203
203
ENTANGLEMENT
HAZARD!
Tie back long hair, roll up
long sleeves, and remove
loose clothing, jewelry, or
gloves to prevent getting
caught in moving parts.
WARNING!
Always keep this
cover closed during
operation.
ENTANGLEMENT
HAZARD!
WARNING!
205
MODEL T33904
20" FLOOR DRILL PRESS
w/LED LIGHT & LASER GUIDE
Date
Mfd. for Grizzly in China
S/N
Motor: 1-1/4 HP, 120V, 1-Phase, 60 Hz
Full-Load Current Rating: 13A
Max. Distance Spindle to Table: 28-5/8"
Max. Distance Spindle to Base: 47-1/8"
Spindle Speeds: 12 (210–3020 RPM)
Spindle Travel: 4-1/2"
Spindle Taper: MT#4
Weight: 235 lbs.
Specifications
WARNING!
To reduce risk of serious personal injury when using this machine:
1. Read and understand owner ’s manual before operating.
2. Always wear approved safety glasses and a face shield.
3. Only plug power cord into a grounded outlet.
4. Disconnect power before setting up or servicing.
5. Avoid spindle entanglement. Tie back long hair, roll up long
sleeves, and DO NOT wear loose clothing, gloves, or jewelry.
6. Keep all guards and covers in place during operation.
7. Clamp workpiece to table to prevent rotation.
8. Avoid putting hands where they could slip into rotating bits.
9. Always remove chuck keys and other tools before starting.
10. Use correct speeds for drill bits and workpiece material.
11. DO NOT expose to rain or use in wet locations.
12. Prevent unauthorized use by children or untrained users.
Do not stare into beam.
Class: II
Wavelength: 650nm
Max. Output: 1m W
LASER RADIATION!
CAUTION!
206
Do not stare into beam.
Class: II
Wavelength: 650nm
Max. Output: 1m W
LASER RADIATION!
CAUTION!
206
207
208
MODEL T33903
17" FLOOR DRILL PRESS
w/LED LIGHT & LASER GUIDE
Date
Mfd. for Grizzly in China
S/N
Motor: 1-1/4 HP, 120V, 1-Phase, 60 Hz
Full-Load Current Rating: 13A
Max. Distance Spindle to Table: 27"
Distance From Spindle to Base: 44-1/4"
Spindle Speeds: 12 (210–3020 RPM)
Spindle Travel: 4-3/4"
Spindle Taper: MT#4
Weight: 223 lbs.
Specifications
WARNING!
To reduce risk of serious personal injury when using this machine:
1. Read and understand owner ’s manual before operating.
2. Always wear approved safety glasses and a face shield.
3. Only plug power cord into a grounded outlet.
4. Disconnect power before setting up or servicing.
5. Avoid spindle entanglement. Tie back long hair, roll up long
sleeves, and DO NOT wear loose clothing, gloves, or jewelry.
6. Keep all guards and covers in place during operation.
7. Clamp workpiece to table to prevent rotation.
8. Avoid putting hands where they could slip into rotating bits.
9. Always remove chuck keys and other tools before starting.
10. Use correct speeds for drill bits and workpiece material.
11. DO NOT expose to rain or use in wet locations.
12. Prevent unauthorized use by children or untrained users.
Labels & Cosmetics
Safety labels help reduce the risk of serious injury caused by machine hazards. If any label comes
off or becomes unreadable, the owner of this machine MUST replace it in the original location
before resuming operations. For replacements, contact (800) 523-4777 or www.grizzly.com.
REF PART # DESCRIPTION REF PART # DESCRIPTION
201 PT33903201 COMBO WARNING LABEL 205 PT33904205 MACHINE ID LABEL (T33904)
202 PT33903202 GRIZZLY LOGO LABEL 206 PT33903206 LASER LABEL
203 PT33903203 ELECTRICITY LABEL 207 PT33903207 TOUCH-UP PAINT, GRIZZLY BLACK
204 PT33903204 ENTANGLEMENT HAZARD LABEL 208 PT33903208 TOUCH-UP PAINT, GRIZZLY GREEN
205 PT33903205 MACHINE ID LABEL (T33903)
