Growatt MAX Series User Manual

61
Model
MAX
50KTL3 LV
MAX
60KTL3 LV
MAX
70KTL3 LV
MAX
80KTL3 LV
Weight
82kg
82kg
82/86kg
82/86kg
Operating
temperature range
-25℃ - +60℃（derating over 45℃）
Noise emission
(typical)
≤60dB(A)
Altitude
4000m
Internal
consumption at
<1W(Note1)
Topology
Transformerless
Cooling
Fan cool
Protection
degree
IP65
Relative humidity
0~100%
DC connection
YF-H4(YUANFAN)
AC connection
Cable gland+OT terminal
Interfaces
Display
LED/WIFI+APP
RS485/USB
Yes
PLC/GPRS/4G
Optional
Warranty: 5 /10
years
Yes/Optional
Certificates and approvals
Grid regulation
AS/NZS 4777.2,CEI 0-21 CEI 0-16,VDE-AR-N 4105
DIN V VDE V 0126-1-1 UTE C 15-712-1 EN 50438
IEC 60068,IEC 61683,IEC 62116,IEC 61727
MEA,PEA,DRRG/DEWA:2016,BDEW,G59/3
, ,
, , ,
,
EMC
EN61000-6-2,EN61000-6-4
Safety
IEC/EN62109-1,IEC/EN62109-2
Note1. Self-consumption less then 25W when AC power supply at night.
Specifications
62
Model
MAX
60KTL3 MV
MAX
70KTL3 MV
MAX
80KTL3 MV
MAX
90KTL3 MV
MAX
100KTL3 MV
Input Data(DC)
Max. recommended
PV power(for
module STC)
9000W
105000W
120000W
130000W
130000W
Max. DC voltage
1100V
Start voltage
250V
Nominal voltage
700V
700V
700V
730V
730V
MPP voltage range
200V-1000V
No. of MPP trackers
6
7
7
7
7
No. of PV strings per
MPP trackers
2
Max. input current per
MPP trackers
26A
Max. short-circuit
current per MPP
trackers
32A
DC overvoltage
category
Category II
Output Data(AC)
AC nominal power
60000W
70000W
80000W
90000W
100000W
Max. AC apparent
power
66600VA
77700VA
88800VA
100000VA
111000VA
Nominal AC
voltage/range
277V/480V
425-540VAC
277V/480V
425-540VAC
277V/480V
425-540VAC
288V/500V
425-540VAC
288V/500V
425-540VAC
AC grid
frequency/range
50/60Hz
45-55Hz/55-65Hz
Max. output current
80.2A
93.6A
107.0A
115.7A
128.6A
Max. inrush
current/duration
20KA/tr:8us,tf:20us
Max. output facult
current/duration
300A/30us
Max. inverter backfe
ed current to PV array
0A
Power
factor(@nominal
>0.99
Adjustable power
factor
0.8leading ...0.8lagging
THDi
<3%
Specifications

Growatt MAX Series Specifications

General

Max. DC Voltage	1100 V
MPPT Voltage Range	200-1000 V
Number of DC Inputs per MPPT	2
Nominal Grid Frequency	50/60 Hz
THDi	<3%
DC Switch	Yes
MPPT	Yes
Communication	WiFi, GPRS, Ethernet
Nominal AC Voltage	400 V
AC Voltage Range	310-480 V
Power Factor	0.8 leading ... 0.8 lagging
Operating Temperature Range	-25°C to +60°C
