Growatt SPH4000 Installation Manual

Inverter topology Non-isolated
Certificate No SAAXXX
3.3 Size and weight
Chart 3.1
A(mm) B(mm) C(mm) weight(kg)
SPH TL BL-UP 450 565 188 27
3.4 The advantage of the unit of SPH
Features below:
 All in one design. Can improve self consumption, back up and also Pinch the valley
 Smart management, work mode can be set
 Safe battery used
 Easy installation
 Two mpp tracker input
4 Unpacking
Please check whether external damage to the goods before unpacking.
After unpacking, please check whether the unit damage or missing parts, if it is happen, please contact with
supplier.
Growatt SPH series and accessories as follows:

Growatt SPH4000 Specifications

General

Model	SPH4000
Category	Inverter
Rated Power	4000 W
Max. DC Voltage	550 V
MPPT Voltage Range	120 V - 500 V
Number of MPPTs	2
AC Output Voltage	230 V
Frequency	50/60Hz
Efficiency	97.5%
Start Voltage	150 V
Nominal DC Voltage	360V
Max. Input Current per MPPT	11 A
AC Nominal Power	4000 W
Max. AC Apparent Power	4000 VA
AC Voltage Range	180 V - 280 V
Power Factor	0.8 leading to 0.8 lagging
THDi	<3%
AC Connection Type	Single phase
Max. Charge/Discharge Power	4000 W
Nominal Battery Voltage	48 V
Communication with BMS	CAN/RS485
Operating Temperature Range	-25°C to +60°C
Protection Degree	IP65
Topology	Transformerless
Weight	25 kg
Max. PV Input Voltage	550 V
Cooling Method	Natural Convection
