Growatt SPH4000 Installation Manual

Dimensions (W /
H / D) in mm
461*565*188
Weight 27KG
Noise emission
(typical)
≤ 25 dB(A)
Altitude
2000m
Self-Consumptio
n
< 10 W
Cooling concept Natural
Relative humidity 100%
Features
DC connection MC4/H4(opt)
AC connection connector
BAT connection
OT Terminal
Display LCD
Interfaces:
RS485/ USB
/CAN/Wi-Fi/GPR
S
yes /yes /yes/yes
Warranty: 5
years / 10 years
yes /opt
Certificates and
approvals
CE, IEC62109, G98/G99, VDE0126-1-1, AS4777, CEI 0-21, VDE-AR-N4105, UTE C 15-712，
EN50549, IEC 61727, IEC 62116, IEC 62040 ,,C10/11,NRS 097-2-1
Note:
1.
*1
Continuous charging current: if there is PV and the PV power is large enough, the maximum
continuous charging power can reach 4000W; If there is no PV, only AC is connected, the maximum
continuous charging power is 3000W.
12.2 DC input terminal parameter
MC4 specification:
2.5mm
2
/14AWG 4mm
2
/12 AWG 6mm
2
/10 AWG 10mm
2
/8AWG
Rated current
(90℃environment)
32A 40A 44A 65A
Nominal system voltage
600V DC(UL)
600V DC(TUV)
Contact resistance
0.25mΩ（model）
Protection grade IP68
Socket contact materials Copper, tin
Insulation materials Thermoplastics UL94 V-0
Ambient temperature range -40℃ to +90℃
Wire stripping length 7.0mm(9/32)

Growatt SPH4000 Specifications

General

Model	SPH4000
Category	Inverter
Rated Power	4000 W
Max. DC Voltage	550 V
MPPT Voltage Range	120 V - 500 V
Number of MPPTs	2
AC Output Voltage	230 V
Frequency	50/60Hz
Efficiency	97.5%
Start Voltage	150 V
Nominal DC Voltage	360V
Max. Input Current per MPPT	11 A
AC Nominal Power	4000 W
Max. AC Apparent Power	4000 VA
AC Voltage Range	180 V - 280 V
Power Factor	0.8 leading to 0.8 lagging
THDi	<3%
AC Connection Type	Single phase
Max. Charge/Discharge Power	4000 W
Nominal Battery Voltage	48 V
Communication with BMS	CAN/RS485
Operating Temperature Range	-25°C to +60°C
Protection Degree	IP65
Topology	Transformerless
Weight	25 kg
Max. PV Input Voltage	550 V
Cooling Method	Natural Convection
