Growatt SPH4000 Installation Manual

Error 405 Relay fault
Restart inverter.
Please contact Growatt service center if restart can’t
solve the problem.
Error 123
Autotest failed
(only in Italy)
Restart inverter.
Please contact Growatt service center if restart can’t
solve the problem.
PV Isolation Low PV isolation too low
Check the connection of PV panels and inverter is
good or not.
Check the PE of inverter is good or not.
OP Short Fault! EPS Output Short Fault
Check the load of EPS.
Check the output of EPS. Especial not connect to grid
NTC Open Internal temperature failed Please contact Growatt service center
Error 406
Model set up not meet with
certification
Please check model set or check the DIP setting
Residual I High Leakage current too high
Check the cable of inverter.
Restart inverter.
Please contact Growatt service center if restart can’t
solve the problem
Error 408 Temperature over range
Please check the temperature is in the range of
specification or not.
PV Voltage High PV voltage higher than datasheet
Please check the voltage of PV input is in the range
of specification or not.
10 Manufacturer Warranty
This certificate represents a 5 year warranty for the Growatt products listed below. Possession of this
certificate validates a standard factory warranty of 5 years from the date of purchase.
Warranted products
This warranty is applicable solely to the following products:
 Growatt SPH3000.
 Growatt SPH3600.
 Growatt SPH4000.
 Growatt SPH4600.
 Growatt SPH5000.
 Growatt SPH6000.
 SPH 3000TL BL-UP
 SPH 3600TL BL-UP
 SPH 4000TL BL-UP
 SPH 4600TL BL-UP
 SPH 5000TL BL-UP
 SPH 6000TL BL-UP
Limited Product Warranty
(Applicable under normal application, installation, use and service conditions) Growatt warrants the above

Growatt SPH4000 Specifications

General

Model	SPH4000
Category	Inverter
Rated Power	4000 W
Max. DC Voltage	550 V
MPPT Voltage Range	120 V - 500 V
Number of MPPTs	2
AC Output Voltage	230 V
Frequency	50/60Hz
Efficiency	97.5%
Start Voltage	150 V
Nominal DC Voltage	360V
Max. Input Current per MPPT	11 A
AC Nominal Power	4000 W
Max. AC Apparent Power	4000 VA
AC Voltage Range	180 V - 280 V
Power Factor	0.8 leading to 0.8 lagging
THDi	<3%
AC Connection Type	Single phase
Max. Charge/Discharge Power	4000 W
Nominal Battery Voltage	48 V
Communication with BMS	CAN/RS485
Operating Temperature Range	-25°C to +60°C
Protection Degree	IP65
Topology	Transformerless
Weight	25 kg
Max. PV Input Voltage	550 V
Cooling Method	Natural Convection
