Growatt SPH4000 Installation Manual

Cable casing diameter 4.5 to 7.8mm(3/16: to 5/16”)
12.3 Torque
Upper cover screws 1.3Nm(10.8 1bf.in)
Dc connector 1.8Nm(16.0 1bf.in)
M6 screwdriver 2Nm(18 1bf.in)
Grounding screw 2Nm(18 1bf.in)
12.4 Appendix
The following chart is the energy storage machine optional appendix list, if there is a need please contact the
Growatt New Energy Technology Co., Ltd or dealer orders (P/N is only for reference and it may be changed).
Name Description GROWATT P/N
Shine link
Used for data record in EU MR00.0007200
Used for data record in Australia MR00.0006100
Shine Wi-Fi COM interface MR00.0004601
SP-CT Wireless meter sensor MR00.0006700
SPM(Single phase meter) RS485 meter sensor MR00.0008800
TPM(three phase meter)
RS485 meter sensor (standard) MR00.0008300
RS485 meter sensor (for Italy) MR00.0008400
13 Certificate
Growatt SPH series inverter apply within the scope of the world, so the inverter have to satisfy different
countries and regions of different safety standards
Model Certificate
Growatt SPH3000
Growatt SPH6000
SPH 3000TL BL-UP
SPH 6000 TL BL-UP
CE,IEC62109,G83,VDE0126-1-1,G59,AS4777,AS/NZS3100,
CEI0-21,VDE-AR-N4105,EN50438,VFR,MEA,PEA,IEC61727,IEC62116
Growatt SPH3600
Growatt SPH4000
Growatt SPH4600
Growatt SPH5000
SPH 3600 TL BL-UP
SPH 4000 TL BL-UP
SPH 4600 TL BL-UP
SPH 5000 TL BL-UP
CE,IEC62109,G83,VDE0126-1-1,G59,AS4777,AS/NZS3100,
CEI0-21,VDE-AR-N4105,EN50438,VFR,IEC61727,IEC62116

Growatt SPH4000 Specifications

General

Model	SPH4000
Category	Inverter
Rated Power	4000 W
Max. DC Voltage	550 V
MPPT Voltage Range	120 V - 500 V
Number of MPPTs	2
AC Output Voltage	230 V
Frequency	50/60Hz
Efficiency	97.5%
Start Voltage	150 V
Nominal DC Voltage	360V
Max. Input Current per MPPT	11 A
AC Nominal Power	4000 W
Max. AC Apparent Power	4000 VA
AC Voltage Range	180 V - 280 V
Power Factor	0.8 leading to 0.8 lagging
THDi	<3%
AC Connection Type	Single phase
Max. Charge/Discharge Power	4000 W
Nominal Battery Voltage	48 V
Communication with BMS	CAN/RS485
Operating Temperature Range	-25°C to +60°C
Protection Degree	IP65
Topology	Transformerless
Weight	25 kg
Max. PV Input Voltage	550 V
Cooling Method	Natural Convection
