Growatt SPH4000 Installation Manual

Maximum output
fault peak current
65A(56uS)
Maximum output
over current
protection
65A
Phase factor at
rate power
1
Displacement
power factor,
configurable*
0.8leading…
0.8lagging
0.8leading…
0.8lagging
0.8leading…
0.8lagging
0.8leading…
0.8lagging
0.8leading…
0.8lagging
0.8leading…0.
8lagging
THDI <3% <3% <3% <3% <3% <3%
AC connection Single phase Single phase Single phase Single phase Single phase Single phase
EPS output data(AC power)
Growatt SPH
&SPH TL BL-
UP
Rated output
apparent power
3000VA&30
00VA
3000VA&368
0VA
3000VA&400
0VA
3000VA&400
0VA
3000VA&400
0VA
3000VA&4000
VA
Nominal voltage 230V 230V 230V 230V 230V 230V
Rated Frequency
AC output
50 Hz 50 Hz 50 Hz 50 Hz 50 Hz 50 Hz
Growatt SPH
&SPH TL BL-UP
Rated output
current
13A/13A 13A/16A 13A/17.5A 13A/17.5 13A/17.5A 13A/17.5A
THDv 3% 3% 3% 3% 3% 3%
Switch time
(SPH
TL BL-UP))
≤10ms ≤10ms ≤10ms ≤10ms ≤10ms ≤10ms
BAT data（DC）
Battery voltage
range
42~59V 42~59V 42~59V 42~59V 42~59V 42~59V
Minimum full
load voltage
46V 48V 48V 48V 48V 48V
Growatt
SPH&SPH TL
BL-UP Rated
charging and
discharging
current
66A& 66A 66A&75A 66A&85A 66A&85A 66A&85A 66A&85A
Growatt
SPH&SPH TL
BL-UP
Continuous
charging /
3000W&300
0W
3000W&368
0 W
*1
3000W&400
0 W
*1
3000W&400
0 W
*1
3000W&400
0 W
*1
3000W&4000
W
*1

Growatt SPH4000 Specifications

General

Model	SPH4000
Category	Inverter
Rated Power	4000 W
Max. DC Voltage	550 V
MPPT Voltage Range	120 V - 500 V
Number of MPPTs	2
AC Output Voltage	230 V
Frequency	50/60Hz
Efficiency	97.5%
Start Voltage	150 V
Nominal DC Voltage	360V
Max. Input Current per MPPT	11 A
AC Nominal Power	4000 W
Max. AC Apparent Power	4000 VA
AC Voltage Range	180 V - 280 V
Power Factor	0.8 leading to 0.8 lagging
THDi	<3%
AC Connection Type	Single phase
Max. Charge/Discharge Power	4000 W
Nominal Battery Voltage	48 V
Communication with BMS	CAN/RS485
Operating Temperature Range	-25°C to +60°C
Protection Degree	IP65
Topology	Transformerless
Weight	25 kg
Max. PV Input Voltage	550 V
Cooling Method	Natural Convection
