System applications
MAGNA3
3
11
Cooling systems
Fig. 11 Functional drawing of a cooling system in a commercial building
TM07 0358 1218
MM
M
T
T
1
2
3
4
67
5
AB
C
Pos. Description
1 Cooling tower
2 Cooling source
3 Primary/secondary system
A Primary pump
B Secondary pump
4 "Primary only" system
C Primary pump
5 Air handling unit
6 Fan coil unit
7 Underfloor/ceiling
