Grundfos magna3 User Manual

Product numbers
MAGNA3
11
62
11. Product numbers
Single-head pumps
Twin-head pumps
Note: Click on the product number and go directly to the performance curve in Grundfos Product Center.
Single-head
pump type
Port-to-port
length
[in. (mm)]
Flange
connection
Cast iron Stainless steel (N)
Page
115 V 208-230 V 115 V 208-230 V
MAGNA3 32-60 F (N) 6 - 1/2 (165) PN 12 98126820 98126822 43
MAGNA3 32-100 F (NA) 6 - 1/2 (165) PN 12 98126824 98126826 44
MAGNA3 40-80 F (N) 8 - 9/16 (216) PN 12 98126800 98126828 98126802 98126830 45
MAGNA3 40-120 F (N) 8 - 9/16 (216) PN 12 98126804 98126832 98126806 98126834 46
MAGNA3 40-180 F (N) 8 - 9/16 (216) PN 12 98126808 98126836 98126810 98126838 47
MAGNA3 50-80 F (N) 9 - 1/2 (240) PN 12 98126812 98126840 98126814 98126842 48
MAGNA3 50-150 F (N) 11 - 1/16 (280) PN 12 98126816 98126844 98126818 98126846 49
MAGNA3 65-120 F (N) 13 - 7/16 (340) PN 12 98124696 98126848 98124702 98126850 50
MAGNA3 65-150 F (N) 13 - 7/16 (340) PN 12 - 98126852 - 98126854 51
MAGNA3 80-100 F (N) 14 - 3/16 (360) PN 12 - 98126856 - 98126858 53
MAGNA3 100-120 F (N) 17 - 3/4 (450) PN 12 - 98126860 - 98126862 55
Twin-head
pump type
Port-to-port
length
[in. (mm)]
Flange
connection
Cast iron Stainless steel (N)
Page
115 V 208-230 V 115 V 208-230 V
MAGNA3 D 65-150 F 13 - 7/16 (340) PN 12 - 98126863 - - 52
MAGNA3 D 80-100 F 14 - 3/16 (360) PN 12 - 98126864 - - 54
MAGNA3 D 100-120 F 17 - 3/4 (450) PN 12 - 98126865 - - 56

Grundfos magna3 Specifications

General

Liquid Temperature Range	-10°C to +110°C
Max Operating Pressure	16 bar
Type	Circulator Pump
Series	MAGNA3
Operating Temperature Range	-10°C to +110°C
Ambient Temperature Range	0°C to +40°C
Protection Class	IPX4D
Power Supply	1 x 230 V, 3 x 230 V, 3 x 400 V
Control Mode	Constant pressure, Proportional pressure
Communication	Modbus RTU
Pump Housing	Cast Iron
Impeller	Composite
Enclosure Class	X4D
Approvals	CE, EAC
Connection	Flange
Weight	Varies depending on model
Power Consumption	Varies depending on model
