Grundfos magna3 - MAGNA3 80-100 F (N) Data

Performance curves and technical data
9
53
MAGNA3 Performance curves and technical data
MAGNA3 80-100 F (N) 1 x 230 V, 60 Hz
For product numbers, see page 62.
H
[ft]
0
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
Q [US gpm]0 40 80 120 160 200 240 280
P1
[W]
0
100
200
300
400
500
600
700
800
900
1,000
1,100
H
[ft]
0
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
Q [US gpm]0 40 80 120 160 200 240 280
P1
[W]
0
100
200
300
400
500
600
700
800
900
1,000
1,100
H
[ft]
0
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
Q [US gpm]0 40 80 120 160 200 240 280
2 V
3 V
4 V
5 V
6 V
7 V
8 V
9 V
10 V
AUTOADAPT
Proportional pressure Constant pressure 0-10 volts*
Speed
P1 [W]
230 V
I
1
[A]
230 V
Min. 31 0.32
Max. 1017 4.51
The pump incorporates overload protection.
Net weights
[lb (kg)]
Ship. vol.
[ft
3
(m
3
)]
66.2 (30.0) 2.47 (0.07)
* External setpoint influence shown with a
setpoint of H
max
Connections: GF80 flanges.
See Pipe connections, page 61.
System pressure: Max. 175 psi (1.2 MPa) (12 bar).
Liquid temperature: 14 to 230 °F (-10 to +110 °C) (TF 110).
Specific EEI: 0.17.
TM05 7652 1413
B2
L5 L1
B7
B4
B6
H3
H1 H6
H4 H2
B1
D1 D2 D3 D4
ØD5
Pump type Dimensions [in (mm)]
MAGNA3 80-100 F (N)
L1 L5 B1 B2 B4 B6 B7 D1 D2
14.17 (360) 8.03 (204) 3.31 (84) 6.46 (164) 2.87 (73) 6.42 (163) 6.42 (163) 3.15 (80) 5.2 (132)
D3 D4 D5 H1 H2 H3 H4 H6
5.91 (150) 7.87 (200) 0.75 (19) 3.7 (94) 12.52 (318) 16.22 (412) 4.53 (115) 2.6 (66)
