Accessories
MAGNA3
10
61
Pipe connections
Material Flange Description Part number
Cast iron
GF 15/26 flange
3/4" NPT flange fitting set 519601
1" NPT flange fitting set 519602
1-1/4" NPT flange fitting set 519603
1-1/2" NPT flange fitting set 519604
GF 40/43 flange 1-1/2" NPT flange fitting set 539605
GF 50 flange 2" NPT flange fitting set 96409354
GF 53 flange
2" NPT flange fitting set 91584910
2-1/2" NPT flange fitting set 91584911
3" NPT flange fitting set 91584912
GF 65 flange 2-1/2" NPT flange fitting set 559601
GF 80 flange 3" NPT flange fitting set 569601
GF 100 flange 4" NPT flange fitting set 579801
Stainless steel GF 65 flange Stainless steel, 2-1/2" NPT flange fitting set 91121951
Replacement flange gaskets
GF 15/40 2-bolt, single o-ring for 1-1/2" flange 98476425
